Testing Kustomize Configurations: conftest, Datree, and Schema Validation

Kustomize makes Kubernetes manifest management tractable. It does not make it safe. Overlays can silently remove resource limits, merge in insecure defaults, or produce structurally invalid YAML that only breaks at apply time. Testing Kustomize configurations before kubectl apply means catching those failures in CI—not during an incident.

The Testing Stack

Four tools cover different failure modes:

Tool Catches
kubeconform Schema violations, unknown fields, API version drift
conftest (OPA) Policy violations, security anti-patterns
Datree Kubernetes best-practice rules, misconfigs
diff tests Unintended overlay changes

Use all four. They don't overlap much.

Schema Validation with kubeconform

kubeconform validates rendered manifests against Kubernetes JSON schemas. It's faster and more accurate than the deprecated kubeval.

Install and run:

brew install kubeconform

# Render kustomize build, pipe to kubeconform
kustomize build overlays/production <span class="hljs-pipe">| kubeconform \
  -strict \
  -ignore-missing-schemas \
  -schema-location default \
  -schema-location <span class="hljs-string">'https://raw.githubusercontent.com/datreeio/CRDs-catalog/main/{{.Group}}/{{.ResourceKind}}_{{.ResourceAPIVersion}}.json' \
  -summary \
  -output tap

The CRDs-catalog URL handles custom resources (Cert-manager, Argo, Flux, etc.) that aren't in the core Kubernetes schemas. Without it, kubeconform silently skips CRDs or errors on unknown schemas.

For all overlays in a monorepo:

#!/bin/bash
<span class="hljs-comment"># scripts/validate-schemas.sh

FAILED=0
<span class="hljs-keyword">for overlay <span class="hljs-keyword">in overlays/*/; <span class="hljs-keyword">do
  <span class="hljs-built_in">echo <span class="hljs-string">"Validating $overlay..."
  kustomize build <span class="hljs-string">"$overlay" <span class="hljs-pipe">| kubeconform \
    -strict \
    -ignore-missing-schemas \
    -schema-location default \
    -schema-location <span class="hljs-string">'https://raw.githubusercontent.com/datreeio/CRDs-catalog/main/{{.Group}}/{{.ResourceKind}}_{{.ResourceAPIVersion}}.json' \
    -summary 2>&1

  <span class="hljs-keyword">if [ <span class="hljs-variable">${PIPESTATUS[1]} -ne 0 ]; <span class="hljs-keyword">then
    <span class="hljs-built_in">echo <span class="hljs-string">"FAILED: $overlay"
    FAILED=1
  <span class="hljs-keyword">fi
<span class="hljs-keyword">done

<span class="hljs-built_in">exit <span class="hljs-variable">$FAILED

Common failures this catches:

  • apiVersion: apps/v1beta1 (removed in Kubernetes 1.16)
  • Missing required fields like selector in Deployments
  • Type mismatches (string where integer expected)

Policy Testing with conftest

conftest evaluates Rego policies against any structured data. For Kubernetes, you pipe rendered manifests and check them against security and operational policies.

Project structure:

policy/
  kubernetes/
    deny_latest_tag.rego
    require_limits.rego
    require_labels.rego
    no_privileged.rego
  lib/
    kubernetes.rego

A policy library to avoid repetition:

# policy/lib/kubernetes.rego
package lib.kubernetes

is_deployment {
  input.kind == "Deployment"
}

is_container(container) {
  container := input.spec.template.spec.containers[_]
}

name := input.metadata.name
namespace := input.metadata.namespace

Actual policy files:

# policy/kubernetes/require_limits.rego
package main

import future.keywords.every

deny[msg] {
  input.kind == "Deployment"
  container := input.spec.template.spec.containers[_]
  not container.resources.limits.memory
  msg := sprintf(
    "Deployment '%s': container '%s' is missing memory limit",
    [input.metadata.name, container.name]
  )
}

deny[msg] {
  input.kind == "Deployment"
  container := input.spec.template.spec.containers[_]
  not container.resources.limits.cpu
  msg := sprintf(
    "Deployment '%s': container '%s' is missing CPU limit",
    [input.metadata.name, container.name]
  )
}

warn[msg] {
  input.kind == "Deployment"
  container := input.spec.template.spec.containers[_]
  not container.resources.requests.memory
  msg := sprintf(
    "Deployment '%s': container '%s' has no memory request",
    [input.metadata.name, container.name]
  )
}
# policy/kubernetes/no_privileged.rego
package main

deny[msg] {
  input.kind == "Deployment"
  container := input.spec.template.spec.containers[_]
  container.securityContext.privileged == true
  msg := sprintf(
    "Deployment '%s': container '%s' runs as privileged",
    [input.metadata.name, container.name]
  )
}

deny[msg] {
  input.kind == "Deployment"
  input.spec.template.spec.hostNetwork == true
  msg := sprintf(
    "Deployment '%s' uses hostNetwork",
    [input.metadata.name]
  )
}
# policy/kubernetes/require_labels.rego
package main

required_labels := {"app", "version", "component"}

deny[msg] {
  input.kind == "Deployment"
  existing := {label | input.metadata.labels[label]}
  missing := required_labels - existing
  count(missing) > 0
  msg := sprintf(
    "Deployment '%s' is missing labels: %v",
    [input.metadata.name, missing]
  )
}

Run against all overlays:

# Test a single overlay
kustomize build overlays/staging <span class="hljs-pipe">| conftest <span class="hljs-built_in">test - \
  --policy policy/kubernetes \
  --all-namespaces

<span class="hljs-comment"># Test with specific output format for CI
kustomize build overlays/production <span class="hljs-pipe">| conftest <span class="hljs-built_in">test - \
  --policy policy/kubernetes \
  --output tap \
  --all-namespaces

Test the policies themselves with conftest's verify command:

# policy/kubernetes/require_limits_test.rego
package main

test_deny_missing_memory_limit {
  deny[_] with input as {
    "kind": "Deployment",
    "metadata": {"name": "test-app"},
    "spec": {
      "template": {
        "spec": {
          "containers": [{
            "name": "app",
            "resources": {"limits": {"cpu": "100m"}}
          }]
        }
      }
    }
  }
}

test_allow_with_limits {
  count(deny) == 0 with input as {
    "kind": "Deployment",
    "metadata": {"name": "test-app"},
    "spec": {
      "template": {
        "spec": {
          "containers": [{
            "name": "app",
            "resources": {
              "limits": {"cpu": "100m", "memory": "128Mi"},
              "requests": {"cpu": "50m", "memory": "64Mi"}
            }
          }]
        }
      }
    }
  }
}
conftest verify --policy policy/kubernetes

Datree Validation

Datree provides 100+ built-in rules covering Kubernetes best practices without writing Rego. It's faster to start with than maintaining custom policies.

# Install
brew tap datreeio/datree
brew install datree

<span class="hljs-comment"># Run against rendered manifests
kustomize build overlays/staging <span class="hljs-pipe">| datree <span class="hljs-built_in">test -

Custom rules in .datree/policies.yaml:

# .datree/policies.yaml
apiVersion: v1
policies:
  - name: production-policy
    isDefault: true
    rules:
      - identifier: CONTAINERS_MISSING_MEMORY_REQUEST_KEY
        messageOnFailure: "Container must have memory request"
      - identifier: DEPLOYMENT_MISSING_LABEL_ENV_VALUE
        messageOnFailure: "Deployment must have 'env' label"
      - identifier: CONTAINERS_MISSING_READINESS_PROBE_KEY
        messageOnFailure: "Container must have readinessProbe"
      - identifier: CONTAINERS_MISSING_LIVENESS_PROBE_KEY
        messageOnFailure: "Container must have livenessProbe"

Diff Testing Between Environments

The most dangerous Kustomize mistakes are silent: an overlay that was supposed to only change replica count also removes a sidecar, or changes a ConfigMap in an unexpected way. Diff tests catch this.

The pattern: render all overlays, commit the output to a rendered/ directory, and fail CI if the diff is unexpected.

#!/bin/bash
<span class="hljs-comment"># scripts/render-all.sh
<span class="hljs-built_in">mkdir -p rendered

<span class="hljs-keyword">for overlay <span class="hljs-keyword">in overlays/*/; <span class="hljs-keyword">do
  name=$(<span class="hljs-built_in">basename <span class="hljs-string">"$overlay")
  kustomize build <span class="hljs-string">"$overlay" > <span class="hljs-string">"rendered/${name}.yaml"
<span class="hljs-keyword">done

In CI, compare rendered output against what's in the PR:

# .github/workflows/kustomize-diff.yml
name: Kustomize Diff

on:
  pull_request:
    paths:
      - 'base/**'
      - 'overlays/**'
      - 'components/**'

jobs:
  diff:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
        with:
          fetch-depth: 0

      - name: Install tools
        run: |
          brew install kustomize kubeconform conftest

      - name: Render current branch
        run: bash scripts/render-all.sh

      - name: Validate schemas
        run: bash scripts/validate-schemas.sh

      - name: Run conftest policies
        run: |
          for f in rendered/*.yaml; do
            conftest test "$f" --policy policy/kubernetes --output tap
          done

      - name: Show diff against main
        run: |
          git fetch origin main
          git diff origin/main -- rendered/

For a more targeted approach, use dyff instead of raw git diff—it understands YAML structure and produces human-readable Kubernetes-aware diffs:

brew install dyff

# Compare staging overlay between branches
git show origin/main:rendered/staging.yaml > /tmp/staging-main.yaml
dyff between /tmp/staging-main.yaml rendered/staging.yaml

GitHub Actions Full Pipeline

# .github/workflows/kustomize-ci.yml
name: Kustomize CI

on:
  pull_request:
    paths: ['base/**', 'overlays/**', 'components/**', 'policy/**']

jobs:
  validate:
    runs-on: ubuntu-latest
    strategy:
      matrix:
        overlay: [development, staging, production]
    steps:
      - uses: actions/checkout@v4

      - name: Setup kustomize
        uses: imranismail/setup-kustomize@v2

      - name: Render overlay
        run: kustomize build overlays/${{ matrix.overlay }} > /tmp/rendered.yaml

      - name: kubeconform
        run: |
          curl -L https://github.com/yannh/kubeconform/releases/latest/download/kubeconform-linux-amd64.tar.gz | tar xz
          ./kubeconform -strict -ignore-missing-schemas \
            -schema-location default \
            -schema-location 'https://raw.githubusercontent.com/datreeio/CRDs-catalog/main/{{.Group}}/{{.ResourceKind}}_{{.ResourceAPIVersion}}.json' \
            -summary /tmp/rendered.yaml

      - name: conftest
        run: |
          wget -q https://github.com/open-policy-agent/conftest/releases/latest/download/conftest_Linux_x86_64.tar.gz
          tar xzf conftest_Linux_x86_64.tar.gz
          ./conftest test /tmp/rendered.yaml --policy policy/kubernetes --output tap

      - name: Upload rendered manifest
        uses: actions/upload-artifact@v4
        with:
          name: rendered-${{ matrix.overlay }}
          path: /tmp/rendered.yaml

Schema validation catches structural errors, conftest catches policy violations, Datree catches operational best-practice violations, and diff tests catch unexpected changes. Running all four takes under 30 seconds and prevents the class of Kubernetes misconfigurations that cause silent misbehavior in production.
