IoT End-to-End Testing: From Device Sensor to Cloud Dashboard

┌─────────────┐    MQTT     ┌──────────────┐    API    ┌───────────────┐
│   IoT       │ ──────────▶ │  Cloud       │ ────────▶ │  Web          │
│   Device    │             │  Platform    │           │  Dashboard    │
│   (real or  │ ◀────────── │  (AWS IoT,   │ ◀──────── │  (React,      │
│   simulated)│  commands   │   Azure IoT) │  updates  │   Vue, etc.)  │
└─────────────┘             └──────────────┘           └───────────────┘
       ▲                           ▲                           ▲
       │                           │                           │
  Device Controller         Platform Verifier         Application Tester

# device_simulator.py
import paho.mqtt.client as mqtt
import json
import time
import random
import threading

class IoTDeviceSimulator:
    """Simulates an IoT sensor device for E2E testing."""

    def __init__(self, device_id, broker='localhost', port=1883):
        self.device_id = device_id
        self.broker = broker
        self.port = port
        self._running = False
        self._temperature = 22.0
        self._humidity = 60.0
        self._connected = threading.Event()

        self.client = mqtt.Client(client_id=device_id)
        self.client.will_set(
            f'devices/{device_id}/status',
            json.dumps({'online': False}),
            qos=1, retain=True
        )
        self.client.on_connect = self._on_connect
        self.client.on_message = self._on_message

    def _on_connect(self, client, userdata, flags, rc):
        if rc == 0:
            # Subscribe to command topics
            self.client.subscribe(f'devices/{self.device_id}/commands/#', qos=1)
            # Publish online status
            self.client.publish(
                f'devices/{self.device_id}/status',
                json.dumps({'online': True, 'firmware': '1.2.3'}),
                qos=1, retain=True
            )
            self._connected.set()

    def _on_message(self, client, userdata, msg):
        """Handle commands from cloud."""
        command = json.loads(msg.payload)
        if 'set_temperature_threshold' in command:
            self._threshold = command['set_temperature_threshold']
        elif 'reset' in command:
            self._temperature = 22.0

    def start(self):
        self.client.connect(self.broker, self.port)
        self.client.loop_start()
        self._connected.wait(timeout=5)
        self._running = True

        # Start publishing sensor data
        threading.Thread(target=self._publish_telemetry, daemon=True).start()
        return self

    def _publish_telemetry(self):
        while self._running:
            # Simulate realistic sensor readings with noise
            self._temperature += random.uniform(-0.1, 0.1)
            self._humidity += random.uniform(-0.5, 0.5)

            self.client.publish(
                f'devices/{self.device_id}/telemetry',
                json.dumps({
                    'device_id': self.device_id,
                    'temperature': round(self._temperature, 2),
                    'humidity': round(self._humidity, 1),
                    'timestamp': int(time.time()),
                }),
                qos=1
            )
            time.sleep(5)  # publish every 5 seconds

    def set_temperature(self, value):
        """Directly set temperature for test scenarios."""
        self._temperature = value

    def stop(self):
        self._running = False
        self.client.publish(
            f'devices/{self.device_id}/status',
            json.dumps({'online': False}),
            qos=1, retain=True
        )
        self.client.loop_stop()
        self.client.disconnect()

# pytest fixture
@pytest.fixture
def simulated_device():
    device = IoTDeviceSimulator('test-device-001').start()
    yield device
    device.stop()

# dut_controller.py — controls real hardware via serial/USB
import serial
import json

class DUTController:
    """Controls a real device under test via serial console."""

    def __init__(self, port='/dev/ttyUSB0', baud=115200):
        self.serial = serial.Serial(port, baud, timeout=5)

    def send_command(self, command):
        self.serial.write((json.dumps(command) + '\n').encode())

    def read_response(self, timeout=5):
        deadline = time.time() + timeout
        while time.time() < deadline:
            line = self.serial.readline().decode().strip()
            if line:
                return json.loads(line)
        raise TimeoutError('No response from device')

    def simulate_sensor_spike(self, value):
        """Trigger a specific sensor reading via test command interface."""
        self.send_command({'test_mode': True, 'temperature_override': value})
        return self.read_response()

import boto3

class AWSIoTVerifier:
    def __init__(self, region='us-east-1'):
        self.iot = boto3.client('iot', region_name=region)
        self.iot_data = boto3.client('iot-data', region_name=region)
        self.dynamodb = boto3.resource('dynamodb', region_name=region)

    def get_device_shadow(self, device_id):
        response = self.iot_data.get_thing_shadow(thingName=device_id)
        return json.loads(response['payload'])

    def wait_for_shadow_update(self, device_id, key, expected_value, timeout=30):
        deadline = time.time() + timeout
        while time.time() < deadline:
            shadow = self.get_device_shadow(device_id)
            reported = shadow.get('state', {}).get('reported', {})
            if reported.get(key) == expected_value:
                return True
            time.sleep(1)
        return False

    def get_latest_telemetry(self, device_id, table_name='device-telemetry'):
        table = self.dynamodb.Table(table_name)
        response = table.query(
            KeyConditionExpression='device_id = :d',
            ExpressionAttributeValues={':d': device_id},
            ScanIndexForward=False,
            Limit=1,
        )
        return response['Items'][0] if response['Items'] else None

    def wait_for_telemetry(self, device_id, min_timestamp, timeout=30):
        deadline = time.time() + timeout
        while time.time() < deadline:
            latest = self.get_latest_telemetry(device_id)
            if latest and latest['timestamp'] >= min_timestamp:
                return latest
            time.sleep(2)
        return None

# test_iot_e2e.py
import pytest
from playwright.sync_api import sync_playwright
import time

def test_temperature_sensor_to_dashboard(simulated_device):
    """Full pipeline: device publishes temperature → cloud processes → dashboard shows value."""

    device_id = 'test-device-001'
    verifier = AWSIoTVerifier()

    # Set a known temperature on the device
    target_temp = 35.7
    publish_time = int(time.time())
    simulated_device.set_temperature(target_temp)

    # Wait for telemetry to reach cloud (MQTT → IoT Core → DynamoDB)
    telemetry = verifier.wait_for_telemetry(device_id, publish_time, timeout=30)
    assert telemetry is not None, 'Telemetry did not reach cloud within 30 seconds'
    assert abs(telemetry['temperature'] - target_temp) < 0.5, \
        f"Expected ~{target_temp}°C in cloud, got {telemetry['temperature']}"

    # Verify dashboard shows the value
    with sync_playwright() as p:
        browser = p.chromium.launch()
        page = browser.new_page()
        page.goto(f'https://dashboard.youriot.com/devices/{device_id}')
        page.wait_for_selector('[data-testid="temperature-reading"]')

        displayed_temp = float(
            page.locator('[data-testid="temperature-reading"]').inner_text()
        )
        assert abs(displayed_temp - target_temp) < 1.0, \
            f"Dashboard shows {displayed_temp}°C, expected ~{target_temp}°C"

        browser.close()

def test_high_temperature_alert_fires(simulated_device):
    """When temperature exceeds threshold, alert should appear in dashboard."""

    device_id = 'test-device-001'
    verifier = AWSIoTVerifier()
    alert_threshold = 40.0

    # Trigger high temperature reading
    simulated_device.set_temperature(alert_threshold + 5)  # 45°C — above threshold
    trigger_time = int(time.time())

    # Verify telemetry reached cloud
    telemetry = verifier.wait_for_telemetry(device_id, trigger_time, timeout=30)
    assert telemetry is not None

    # Verify alert in dashboard
    with sync_playwright() as p:
        browser = p.chromium.launch()
        page = browser.new_page()
        page.goto(f'https://dashboard.youriot.com/devices/{device_id}/alerts')

        # Wait for alert to appear (processing delay expected)
        page.wait_for_selector('[data-testid="active-alert"]', timeout=15000)

        alert_text = page.locator('[data-testid="active-alert"]').inner_text()
        assert 'temperature' in alert_text.lower()
        assert str(int(alert_threshold)) in alert_text

        browser.close()

def test_device_command_reaches_device(simulated_device):
    """Command issued from dashboard should be received by device."""

    device_id = 'test-device-001'
    received_commands = []

    # Monitor device command topic
    def command_received(msg):
        received_commands.append(json.loads(msg.payload))

    monitor = MQTTTestClient().connect()
    monitor.subscribe(f'devices/{device_id}/commands/#')

    # Send command from dashboard
    with sync_playwright() as p:
        browser = p.chromium.launch()
        page = browser.new_page()
        page.goto(f'https://dashboard.youriot.com/devices/{device_id}/controls')

        page.locator('[data-testid="set-threshold-input"]').fill('38')
        page.locator('[data-testid="apply-threshold-btn"]').click()
        page.wait_for_selector('[data-testid="command-sent-confirmation"]')

        browser.close()

    # Verify command reached device
    time.sleep(5)  # allow MQTT propagation
    monitor.disconnect()

    assert len(received_commands) > 0, 'No command received by device'
    assert any(
        cmd.get('set_temperature_threshold') == 38
        for cmd in received_commands
    ), 'Expected threshold command not received'

def test_device_offline_status_shown(simulated_device):
    """When device disconnects, dashboard should show offline status."""

    device_id = 'test-device-001'

    with sync_playwright() as p:
        browser = p.chromium.launch()
        page = browser.new_page()
        page.goto(f'https://dashboard.youriot.com/devices/{device_id}')

        # Verify initially online
        page.wait_for_selector('[data-testid="device-status-online"]')

        # Disconnect device
        simulated_device.stop()

        # LWT message should trigger offline status
        page.wait_for_selector('[data-testid="device-status-offline"]', timeout=15000)

        status_text = page.locator('[data-testid="device-status-offline"]').inner_text()
        assert 'offline' in status_text.lower()

        browser.close()

def test_telemetry_stored_correctly():
    """Verify telemetry data is stored with correct schema in database."""
    device_id = 'test-device-001'
    device = IoTDeviceSimulator(device_id).start()

    try:
        device.set_temperature(22.5)
        publish_time = int(time.time())

        verifier = AWSIoTVerifier()
        record = verifier.wait_for_telemetry(device_id, publish_time, timeout=30)

        assert record is not None
        assert record['device_id'] == device_id
        assert 'temperature' in record
        assert 'humidity' in record
        assert 'timestamp' in record
        assert record['timestamp'] >= publish_time
        # Verify temperature is within realistic range
        assert -40 <= record['temperature'] <= 85
    finally:
        device.stop()

def test_data_not_stored_for_unknown_device():
    """Telemetry from unregistered devices should be rejected."""
    unknown_device = IoTDeviceSimulator('unregistered-device-999').start()

    try:
        unknown_device.set_temperature(22.0)
        publish_time = int(time.time())

        time.sleep(10)  # allow processing time

        verifier = AWSIoTVerifier()
        # Nothing should be stored for unregistered device
        record = verifier.get_latest_telemetry('unregistered-device-999')
        assert record is None or record['timestamp'] < publish_time
    finally:
        unknown_device.stop()

# conftest.py
@pytest.fixture(scope='session')
def test_environment():
    """Create isolated test resources for the session."""
    env = {
        'device_id': f'test-device-{int(time.time())}',
        'alert_rule_id': None,
    }

    # Create test device in IoT platform
    iot = boto3.client('iot')
    iot.create_thing(thingName=env['device_id'])

    yield env

    # Cleanup: delete test device and data
    iot.delete_thing(thingName=env['device_id'])
    # Clean up DynamoDB test records
    cleanup_test_telemetry(env['device_id'])

@pytest.fixture
def simulated_device(test_environment):
    device = IoTDeviceSimulator(
        test_environment['device_id']
    ).start()
    yield device
    device.stop()

name: IoT E2E Tests

on:
  push:
    branches: [main]

jobs:
  e2e-tests:
    runs-on: ubuntu-latest
    environment: staging
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-python@v5
        with:
          python-version: '3.12'

      - name: Install dependencies
        run: |
          pip install paho-mqtt pytest playwright boto3
          playwright install chromium

      - name: Start MQTT broker (for protocol tests)
        run: docker run -d -p 1883:1883 eclipse-mosquitto:2

      - name: Run IoT E2E tests
        run: pytest tests/e2e/iot/ -v --timeout=120
        env:
          AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
          AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
          DASHBOARD_URL: ${{ vars.STAGING_DASHBOARD_URL }}
          IOT_BROKER_URL: ${{ vars.STAGING_IOT_BROKER }}
