Testing GraphQL Persisted Queries and Automatic Persisted Queries (APQ)

HelpMeTest

24 May 2026 — 6 min read

GraphQL persisted queries reduce payload size and improve security by replacing full query strings with short hash identifiers. But they introduce new failure modes — hash mismatches, cache invalidation bugs, and APQ negotiation failures — that require dedicated testing strategies.

This guide covers everything you need to test persisted queries and APQ implementations reliably.

What Are Persisted Queries?

Standard GraphQL sends the full query string on every request:

{
  "query": "query GetUser($id: ID!) { user(id: $id) { name email } }",
  "variables": { "id": "123" }
}

With persisted queries, you register queries ahead of time and send only their hash:

{
  "extensions": {
    "persistedQuery": {
      "version": 1,
      "sha256Hash": "ecf4edb46db40b5132295c0291d62fb65d6759a9aca10d700549df22f1ae1dac"
    }
  },
  "variables": { "id": "123" }
}

The server looks up the hash and executes the stored query. If the hash isn't found, the client falls back to sending the full query (APQ negotiation).

APQ Negotiation Flow

Automatic Persisted Queries (APQ) follow a two-step protocol:

First request — client sends hash only, no query string
If hash unknown — server returns PersistedQueryNotFound error
Second request — client resends with both hash AND full query string
Server stores the query, executes it, returns result
Subsequent requests — hash-only works

This flow is critical to test because failures at any step silently degrade to full-query mode, defeating the performance benefit.

Setting Up Test Infrastructure

Test Client with APQ Support

import { ApolloClient, InMemoryCache, HttpLink } from '@apollo/client';
import { createPersistedQueryLink } from '@apollo/client/link/persisted-queries';
import { sha256 } from 'crypto-hash';

const persistedQueryLink = createPersistedQueryLink({ sha256 });
const httpLink = new HttpLink({ uri: 'http://localhost:4000/graphql' });

const client = new ApolloClient({
  link: persistedQueryLink.concat(httpLink),
  cache: new InMemoryCache(),
});

Direct HTTP Testing (No Client Library)

For lower-level tests, use raw HTTP to inspect APQ negotiation:

import crypto from 'crypto';

function hashQuery(query) {
  return crypto.createHash('sha256').update(query).digest('hex');
}

async function sendPersistedQuery(hash, query = null, variables = {}) {
  const body = {
    extensions: {
      persistedQuery: { version: 1, sha256Hash: hash }
    },
    variables,
  };
  if (query) body.query = query;

  const res = await fetch('http://localhost:4000/graphql', {
    method: 'POST',
    headers: { 'Content-Type': 'application/json' },
    body: JSON.stringify(body),
  });
  return res.json();
}

Core Test Cases

Test 1: APQ Full Negotiation Flow

Verify the complete two-step APQ handshake works end-to-end:

describe('APQ Negotiation', () => {
  const GET_USER_QUERY = `
    query GetUser($id: ID!) {
      user(id: $id) { id name email }
    }
  `;
  const queryHash = hashQuery(GET_USER_QUERY);

  it('should complete APQ negotiation in two requests', async () => {
    // Step 1: Send hash only — expect PersistedQueryNotFound
    const firstResponse = await sendPersistedQuery(queryHash, null, { id: '1' });

    expect(firstResponse.errors).toBeDefined();
    expect(firstResponse.errors[0].message).toBe('PersistedQueryNotFound');
    expect(firstResponse.errors[0].extensions.code).toBe('PERSISTED_QUERY_NOT_FOUND');

    // Step 2: Send hash + full query — expect successful registration and execution
    const secondResponse = await sendPersistedQuery(queryHash, GET_USER_QUERY, { id: '1' });

    expect(secondResponse.errors).toBeUndefined();
    expect(secondResponse.data.user).toBeDefined();
    expect(secondResponse.data.user.id).toBe('1');
  });

  it('should serve from cache on third request', async () => {
    // After negotiation, hash-only should work
    const cachedResponse = await sendPersistedQuery(queryHash, null, { id: '1' });

    expect(cachedResponse.errors).toBeUndefined();
    expect(cachedResponse.data.user).toBeDefined();
  });
});

Test 2: Hash Verification

The server must reject requests where the hash doesn't match the query:

describe('Hash Verification', () => {
  it('should reject mismatched hash and query', async () => {
    const REAL_QUERY = `query { users { id name } }`;
    const DIFFERENT_QUERY = `query { products { id title } }`;
    const wrongHash = hashQuery(DIFFERENT_QUERY);

    const response = await sendPersistedQuery(wrongHash, REAL_QUERY);

    // Server should detect hash/query mismatch
    expect(response.errors).toBeDefined();
    expect(response.errors[0].extensions.code).toBe('PERSISTED_QUERY_NOT_FOUND');
    // Or a specific validation error depending on implementation
  });

  it('should reject tampered hash', async () => {
    const query = `query { me { id } }`;
    const tamperedHash = 'a'.repeat(64); // Not the real hash

    const response = await sendPersistedQuery(tamperedHash, query);

    expect(response.errors).toBeDefined();
  });
});

Test 3: Cache Invalidation After Schema Changes

After a schema update, cached queries that reference removed fields should fail gracefully:

describe('Cache Invalidation', () => {
  it('should handle removed field after schema update', async () => {
    // Register a query that uses a field that will be "removed"
    const queryWithDeprecatedField = `
      query GetUser($id: ID!) {
        user(id: $id) { id name legacyUsername }
      }
    `;
    const hash = hashQuery(queryWithDeprecatedField);

    // Register it
    await sendPersistedQuery(hash, queryWithDeprecatedField, { id: '1' });

    // Simulate what happens when the query is served but field doesn't exist
    const response = await sendPersistedQuery(hash, null, { id: '1' });

    // Should get a GraphQL field error, not a network error
    if (response.errors) {
      expect(response.errors[0].path).toBeDefined();
      expect(response.errors[0].extensions?.code).not.toBe('PERSISTED_QUERY_NOT_FOUND');
    }
    // Partial data is acceptable if other fields resolve
  });
});

Test 4: Pre-Registered Queries (Static Manifest)

Many teams pre-register queries in a manifest file for enhanced security (only allow-listed queries execute):

// queries-manifest.json
// {
//   "operations": {
//     "GetUser": { "id": "ecf4edb4...", "body": "query GetUser..." }
//   }
// }

describe('Static Query Allow-list', () => {
  it('should execute pre-registered query by hash', async () => {
    const manifest = JSON.parse(fs.readFileSync('./queries-manifest.json', 'utf8'));
    const op = manifest.operations.GetUser;

    const response = await sendPersistedQuery(op.id, null, { id: '1' });

    expect(response.errors).toBeUndefined();
    expect(response.data).toBeDefined();
  });

  it('should reject arbitrary query not in allow-list', async () => {
    const arbitraryQuery = `query { __schema { types { name } } }`;
    const hash = hashQuery(arbitraryQuery);

    // First, try with full query (APQ registration attempt)
    const response = await sendPersistedQuery(hash, arbitraryQuery);

    // In strict allow-list mode, this should be rejected
    expect(response.errors).toBeDefined();
    // Error code varies by implementation
    expect(['PERSISTED_QUERY_NOT_FOUND', 'FORBIDDEN', 'BAD_USER_INPUT'])
      .toContain(response.errors[0].extensions?.code);
  });
});

Performance Testing

One of the main reasons for persisted queries is bandwidth reduction. Verify this works:

describe('Payload Size Reduction', () => {
  it('should reduce request payload size', async () => {
    const largeQuery = `
      query GetDashboardData($userId: ID!, $orgId: ID!) {
        user(id: $userId) {
          id name email avatar
          organization { id name plan }
          recentActivity(limit: 10) {
            id type createdAt
            details { key value }
          }
        }
        organization(id: $orgId) {
          members { id name role }
          projects { id title status }
        }
      }
    `;
    const hash = hashQuery(largeQuery);
    const variables = { userId: '1', orgId: 'org-1' };

    // Register the query
    await sendPersistedQuery(hash, largeQuery, variables);

    // Measure payload sizes
    const fullQueryPayload = JSON.stringify({ query: largeQuery, variables });
    const persistedPayload = JSON.stringify({
      extensions: { persistedQuery: { version: 1, sha256Hash: hash } },
      variables,
    });

    console.log('Full query bytes:', fullQueryPayload.length);
    console.log('Persisted query bytes:', persistedPayload.length);

    expect(persistedPayload.length).toBeLessThan(fullQueryPayload.length);
  });
});

Security Testing

Introspection via Persisted Queries

If your API disables introspection in production but persisted queries bypass that check:

describe('Security', () => {
  it('should apply security rules to persisted queries', async () => {
    const introspectionQuery = `
      query IntrospectionQuery {
        __schema {
          queryType { name }
          types { name kind }
        }
      }
    `;
    const hash = hashQuery(introspectionQuery);

    // Try to register and execute introspection
    const registerResponse = await sendPersistedQuery(hash, introspectionQuery);

    if (registerResponse.errors) {
      // APQ registration rejected — good
      expect(registerResponse.errors[0].message).toMatch(/introspection|forbidden/i);
    } else {
      // If registered, subsequent calls should also be blocked or return same result
      const executionResponse = await sendPersistedQuery(hash);
      expect(executionResponse).toEqual(registerResponse);
    }
  });
});

Testing with Apollo Studio / Client Tooling

When using Apollo Client's createPersistedQueryLink, integration tests look like standard Apollo tests but APQ happens transparently:

import { render, screen, waitFor } from '@testing-library/react';
import { MockedProvider } from '@apollo/client/testing';
import { GET_USER } from './queries';

// For unit tests — mock the response, APQ handled by link
const mocks = [{
  request: {
    query: GET_USER,
    variables: { id: '1' },
  },
  result: {
    data: { user: { id: '1', name: 'Alice' } },
  },
}];

test('UserProfile renders with persisted query', async () => {
  render(
    <MockedProvider mocks={mocks} addTypename={false}>
      <UserProfile userId="1" />
    </MockedProvider>
  );

  await waitFor(() => {
    expect(screen.getByText('Alice')).toBeInTheDocument();
  });
});

For E2E tests that validate the actual APQ negotiation, intercept network requests with Playwright:

import { test, expect } from '@playwright/test';

test('APQ negotiation happens on first page load', async ({ page }) => {
  const graphqlRequests = [];

  page.on('request', req => {
    if (req.url().includes('/graphql')) {
      graphqlRequests.push(JSON.parse(req.postData() || '{}'));
    }
  });

  await page.goto('/profile/1');
  await page.waitForSelector('[data-testid="user-name"]');

  // Check that APQ was used
  const persistedRequests = graphqlRequests.filter(
    r => r.extensions?.persistedQuery
  );
  expect(persistedRequests.length).toBeGreaterThan(0);

  // First request should not have query string (hash-only attempt)
  const firstPersisted = persistedRequests[0];
  expect(firstPersisted.query).toBeUndefined();
});

Common Bugs to Test For

Bug	Test Approach
Server stores query but doesn't validate hash	Submit wrong hash with full query, verify rejection
APQ fallback disabled	Check `PersistedQueryNotFound` triggers resend correctly
Cache not shared across server instances	Run negotiation on instance A, test hash-only on instance B
Stale cache after query updates	Deploy new query version, verify old hash still works or fails cleanly
Security bypass via APQ	Test that allow-list enforcement applies to APQ-registered queries

Checklist

Before shipping a persisted query implementation:

APQ two-step negotiation completes successfully
Hash mismatch is rejected with proper error code
Pre-registered queries execute from manifest
Arbitrary queries rejected in allow-list mode
Security rules (rate limits, auth, introspection block) apply to persisted queries
Cache survives server restart (if using Redis/external cache)
Payload size reduction is measurable and significant
E2E tests verify APQ headers in real network requests

Persisted queries are a small protocol extension with surprisingly large attack surface. Testing both the happy path and the security properties ensures you get the performance benefits without introducing new vulnerabilities.
