Developer Platform Reliability: SLOs, Chaos Testing, and Platform Health Checks

# slos/ci-cd.yaml
slos:
  - name: "CI Pipeline Availability"
    description: "Percentage of CI pipeline runs that complete (pass or fail) without infrastructure errors"
    indicator:
      type: ratio
      good_events: "ci_runs{outcome!='infrastructure_error'}"
      total_events: "ci_runs_total"
    target: 99.5  # 0.5% allowed infrastructure failure rate
    window: 30d

  - name: "CI Pipeline Latency"
    description: "Percentage of CI runs that complete within 20 minutes"
    indicator:
      type: ratio
      good_events: "ci_run_duration_seconds{le='1200'}"  # 20 min = 1200s
      total_events: "ci_runs_total"
    target: 95.0  # 5% can be slow
    window: 30d

  - name: "Artifact Push Availability"
    description: "Successful Docker image pushes to registry"
    indicator:
      type: ratio
      good_events: "registry_push{status='200'}"
      total_events: "registry_push_total"
    target: 99.9
    window: 30d

  - name: "Secret Retrieval Availability"
    description: "Applications can read secrets on startup"
    indicator:
      type: ratio
      good_events: "secret_reads{status='success'}"
      total_events: "secret_reads_total"
    target: 99.99  # Four nines — startup failures are critical
    window: 30d

  - name: "Secret Retrieval Latency"
    description: "Secret reads complete under 500ms"
    indicator:
      type: ratio
      good_events: "secret_read_duration_ms{le='500'}"
      total_events: "secret_reads_total"
    target: 99.0
    window: 30d

  - name: "Developer Portal Availability"
    description: "Portal loads successfully for engineers"
    indicator:
      type: availability
      probe: "https://internal.example.com/health"
      expected_status: 200
    target: 99.5  # Lower target — planned maintenance is more acceptable
    window: 30d

  - name: "Service Catalog Freshness"
    description: "Service entities updated within 1 hour of GitHub push"
    indicator:
      type: freshness
      max_staleness_minutes: 60
    target: 99.0
    window: 30d

# prometheus/recording-rules.yaml
groups:
  - name: platform_slos
    interval: 30s
    rules:
      # CI Pipeline availability
      - record: ci:run_success_rate:5m
        expr: |
          sum(rate(ci_runs_total{outcome!="infrastructure_error"}[5m]))
          /
          sum(rate(ci_runs_total[5m]))

      # Error budget consumption rate
      - record: ci:error_budget_consumed:1h
        expr: |
          1 - ci:run_success_rate:5m
          # Compare to allowed error rate (0.5% = 0.005)

# tests/slos/test_slo_compliance.py
import pytest
import httpx
from datetime import datetime, timedelta

PROMETHEUS = "http://prometheus:9090"

def query_prometheus(query, start=None, end=None, step="60s"):
    if start and end:
        r = httpx.get(f"{PROMETHEUS}/api/v1/query_range", params={
            "query": query,
            "start": start.isoformat(),
            "end": end.isoformat(),
            "step": step
        })
    else:
        r = httpx.get(f"{PROMETHEUS}/api/v1/query", params={"query": query})

    r.raise_for_status()
    return r.json()

def test_ci_availability_slo_met():
    """CI pipeline availability should meet 99.5% SLO over the last 30 days."""
    end = datetime.now()
    start = end - timedelta(days=30)

    result = query_prometheus(
        'sum(increase(ci_runs_total{outcome!="infrastructure_error"}[30d])) / sum(increase(ci_runs_total[30d]))',
        start=start, end=end
    )

    data = result["data"]["result"]
    if not data:
        pytest.skip("No CI run data available")

    availability = float(data[0]["values"][-1][1])
    assert availability >= 0.995, \
        f"CI availability SLO breached: {availability:.3%} < 99.5%"

def test_secret_retrieval_latency_slo_met():
    """99% of secret reads should complete in under 500ms."""
    result = query_prometheus(
        'histogram_quantile(0.99, sum(rate(secret_read_duration_ms_bucket[30d])) by (le))'
    )

    data = result["data"]["result"]
    if not data:
        pytest.skip("No secret read metrics available")

    p99_ms = float(data[0]["value"][1])
    assert p99_ms <= 500, \
        f"Secret retrieval p99 latency SLO breached: {p99_ms}ms > 500ms"

def test_error_budget_not_exhausted():
    """Error budget should not be more than 80% consumed."""
    # 30-day window, 99.5% target = 0.5% error budget
    # 0.5% of 30 days = 216 minutes of allowed downtime

    result = query_prometheus(
        'sum(increase(ci_runs_total{outcome="infrastructure_error"}[30d])) / sum(increase(ci_runs_total[30d]))'
    )

    data = result["data"]["result"]
    if not data:
        pytest.skip("No data available")

    actual_error_rate = float(data[0]["value"][1])
    allowed_error_rate = 0.005  # 99.5% SLO
    budget_consumed = actual_error_rate / allowed_error_rate

    assert budget_consumed <= 0.8, \
        f"Error budget {budget_consumed:.0%} consumed (threshold: 80%)"

# chaos/test_registry_outage.py
"""Test CI pipeline behavior when artifact registry is unavailable."""
import subprocess
import time
import pytest

@pytest.fixture
def blocked_registry(docker_network):
    """Block traffic to the artifact registry."""
    # Use iptables or tc-netem to simulate registry outage
    subprocess.run([
        "iptables", "-A", "OUTPUT",
        "-d", "registry.example.com",
        "-j", "DROP"
    ], check=True)

    yield

    # Restore
    subprocess.run([
        "iptables", "-D", "OUTPUT",
        "-d", "registry.example.com",
        "-j", "DROP"
    ], check=True)

def test_ci_pipeline_fails_gracefully_on_registry_outage(blocked_registry):
    """CI pipeline should fail with a clear error, not hang indefinitely."""
    start = time.time()

    # Trigger a pipeline that requires a registry push
    result = trigger_test_pipeline(timeout=120)

    elapsed = time.time() - start

    # Should fail, not hang
    assert result["status"] == "FAILURE"
    assert elapsed < 120, "Pipeline hung instead of failing fast"

    # Error should mention the registry, not be a cryptic timeout
    assert any(
        keyword in result["error_message"].lower()
        for keyword in ["registry", "push", "network", "connection"]
    ), f"Unclear error message: {result['error_message']}"

# chaos/test_vault_latency.py
"""Test application startup with slow Vault responses."""
import requests
import time
import threading

def inject_latency(target_host, delay_ms=2000, duration_seconds=30):
    """Use toxiproxy to inject latency into Vault connections."""
    toxiproxy = requests.Session()
    toxiproxy.headers["Content-Type"] = "application/json"

    # Add latency toxic
    toxic_payload = {
        "name": "vault_latency",
        "type": "latency",
        "attributes": {"latency": delay_ms, "jitter": 100}
    }
    toxiproxy.post(
        f"http://toxiproxy:8474/proxies/vault/toxics",
        json=toxic_payload
    )

    time.sleep(duration_seconds)

    # Remove toxic
    toxiproxy.delete("http://toxiproxy:8474/proxies/vault/toxics/vault_latency")

def test_app_starts_despite_slow_vault():
    """Applications should start successfully even if Vault is slow."""
    # Inject 2-second latency
    latency_thread = threading.Thread(
        target=inject_latency,
        args=("vault", 2000, 60),
        daemon=True
    )
    latency_thread.start()

    # Try starting the application
    start = time.time()
    app_process = start_test_application()
    ready = wait_for_ready(app_process, timeout=30)
    elapsed = time.time() - start

    assert ready, f"Application failed to start within 30s under Vault latency"
    assert elapsed < 30, f"Application startup took {elapsed:.1f}s — too slow"

    app_process.terminate()

def test_app_handles_vault_unavailable():
    """Application should start with cached/default secrets when Vault is down."""
    # Block Vault entirely
    block_service("vault")

    try:
        app_process = start_test_application()
        ready = wait_for_ready(app_process, timeout=10)

        if not ready:
            # Acceptable: app refuses to start without secrets
            # Verify it exits cleanly with a meaningful error
            returncode = app_process.wait(timeout=5)
            assert returncode != 0
            logs = app_process.stderr.read().decode()
            assert "vault" in logs.lower() or "secret" in logs.lower()
        else:
            # Also acceptable: app starts with fallback config
            # Verify it reports degraded state
            health = requests.get("http://localhost:8080/health").json()
            assert health["status"] in ("degraded", "partial")
    finally:
        unblock_service("vault")
        if app_process.poll() is None:
            app_process.terminate()

def test_portal_serves_stale_data_when_db_slow():
    """Portal should serve cached data and display staleness warning under DB load."""
    # Inject CPU stress on the database host
    inject_cpu_stress(target="postgres-portal", cpu_percent=90, duration=30)

    response = requests.get("https://internal.example.com/api/catalog/services")

    # Portal should still respond
    assert response.status_code == 200

    # But should indicate data may be stale
    assert response.json().get("stale") is True or \
           "X-Data-Staleness" in response.headers

    # Response should still be fast (served from cache)
    assert response.elapsed.total_seconds() < 2.0

# tests/platform_health/test_health_checks.py
"""Synthetic monitoring for developer platform components."""
import pytest
import httpx
import subprocess

def test_ci_can_start_new_run():
    """Verify CI is accepting new pipeline triggers."""
    r = httpx.post(
        "https://api.github.com/repos/org/smoke-test/dispatches",
        json={"event_type": "health_check"},
        headers={"Authorization": f"token {GITHUB_TOKEN}"}
    )
    assert r.status_code == 204, f"CI dispatch failed: {r.text}"

def test_artifact_registry_push_pull():
    """Verify the artifact registry accepts push and pull."""
    # Push a tiny test image
    subprocess.run([
        "docker", "build", "-t", "registry.example.com/smoke:latest",
        "-f", "-", "."
    ], input=b"FROM scratch", check=True, capture_output=True)

    push_result = subprocess.run([
        "docker", "push", "registry.example.com/smoke:latest"
    ], capture_output=True)
    assert push_result.returncode == 0, f"Registry push failed: {push_result.stderr}"

    # Pull it back
    pull_result = subprocess.run([
        "docker", "pull", "registry.example.com/smoke:latest"
    ], capture_output=True)
    assert pull_result.returncode == 0, f"Registry pull failed: {pull_result.stderr}"

def test_vault_secret_accessible():
    """Verify Vault is reachable and can return secrets."""
    import hvac
    client = hvac.Client(url=VAULT_ADDR, token=VAULT_TOKEN)

    secret = client.secrets.kv.v2.read_secret_version(
        path="smoke-test/health-check"
    )
    assert secret["data"]["data"]["value"] == "ok"

def test_internal_portal_returns_200():
    r = httpx.get("https://internal.example.com/health", timeout=10)
    assert r.status_code == 200

def test_portal_service_catalog_not_empty():
    r = httpx.get(
        "https://internal.example.com/api/catalog/services",
        headers={"Authorization": f"Bearer {PORTAL_TOKEN}"}
    )
    assert r.status_code == 200
    services = r.json()["items"]
    assert len(services) > 0, "Service catalog is empty — sync may have broken"

def test_grafana_datasource_healthy():
    """Grafana's datasources should all be working."""
    r = httpx.get(
        "https://grafana.internal.example.com/api/datasources",
        auth=("admin", GRAFANA_PASSWORD)
    )
    datasources = r.json()

    for ds in datasources:
        health_r = httpx.get(
            f"https://grafana.internal.example.com/api/datasources/{ds['id']}/health",
            auth=("admin", GRAFANA_PASSWORD)
        )
        assert health_r.json()["status"] == "OK", \
            f"Datasource '{ds['name']}' unhealthy: {health_r.json()['message']}"

# Portal availability check
Go To https://internal.example.com/health
Status Should Be 200
Page Should Contain "status":"ok"

# CI API availability
GET https://api.github.com/repos/org/status
Status Should Be 200

# prometheus/alerts.yaml
groups:
  - name: platform_slos
    rules:
      - alert: CIPipelineAvailabilitySLOAtRisk
        expr: |
          (
            1 - sum(rate(ci_runs_total{outcome!="infrastructure_error"}[6h]))
            /
            sum(rate(ci_runs_total[6h]))
          ) > 0.005  # Burning error budget faster than 1x
        for: 30m
        labels:
          severity: warning
          team: platform
        annotations:
          summary: "CI pipeline error budget burning fast"
          description: >
            CI pipeline error rate over 6h is {{ $value | humanizePercentage }}.
            At this rate, the 30-day SLO (99.5%) will be breached.
            Error budget consumed: ~{{ $value | humanizePercentage }} of monthly allowance per day.

      - alert: VaultLatencySLOBreach
        expr: |
          histogram_quantile(0.99,
            sum(rate(secret_read_duration_ms_bucket[1h])) by (le)
          ) > 500
        for: 10m
        labels:
          severity: critical
          team: platform
        annotations:
          summary: "Vault p99 latency exceeds SLO"
          description: >
            Vault secret retrieval p99 latency is {{ $value }}ms.
            SLO target: 500ms. Applications may be experiencing slow startup.
