Basic AFL++ usage — compile with afl-clang-fast, create a seed corpus, run afl-fuzz — finds bugs. Advanced AFL++ usage finds them 10–100x faster, or finds bugs that basic usage misses entirely.

This post covers the techniques that make AFL++ effective against hard targets: persistent mode, comparison logging, custom mutators, and alternative instrumentation modes.

Persistent Mode: The Single Biggest Speedup

Every AFL++ execution in standard mode forks a new child process, feeds it input, and waits for it to exit. Fork overhead limits throughput to ~1,000–10,000 executions/second.

Persistent mode runs the target function in a loop within a single process:

#include "afl-fuzz.h"

int main(int argc, char *argv[]) {
    // One-time setup
    initialize_global_state();

    // AFL++ persistent mode: runs the loop inside a single process
    while (__AFL_LOOP(10000)) {  // 10000 iterations per fork, then restart
        // Read input
        uint8_t *buf;
        ssize_t len = __AFL_LOOP_BUF(&buf);

        // Fuzz target
        parse_input(buf, len);
    }

    return 0;
}

Speedup: typically 10–40x over fork mode for in-memory targets.

The __AFL_LOOP(N) macro runs N iterations in the same process, then allows AFL++ to fork a fresh child. The N value balances speed (more iterations before fork = faster) against state contamination (state accumulates over iterations).

Start with N=1000. If you see coverage inconsistencies or false positives, reduce N. If coverage is clean, increase to 10000+.

Shared memory input (FUZZ_USE_SHM)

AFL++ can pass inputs via shared memory instead of stdin or file I/O, eliminating the file write/read overhead:

#include "afl-fuzz.h"

int main(int argc, char *argv[]) {
    // Shared memory buffer - AFL++ writes input here directly
    __AFL_INIT();

    unsigned char *buf = __AFL_FUZZ_TESTCASE_BUF;

    while (__AFL_LOOP(10000)) {
        int len = __AFL_FUZZ_TESTCASE_LEN;

        parse_input(buf, len);
    }

    return 0;
}

Combined with persistent mode, shared memory input can push throughput to 500,000–1,000,000 executions/second for fast targets.

Deferred forkserver

If initialization (loading config, parsing schema, opening databases) is slow but must happen once, use deferred forkserver to run setup before the first fork:

int main(int argc, char *argv[]) {
    // Expensive one-time setup
    load_large_database();
    initialize_complex_state();

    // Fork server starts HERE - initialization is done in the parent
    // All children get this state for free (copy-on-write)
    __AFL_INIT();

    while (__AFL_LOOP(1000)) {
        uint8_t buf[4096];
        ssize_t len = read(0, buf, sizeof(buf));
        process(buf, len);
    }

    return 0;
}

Without deferred forkserver, each fork runs the initialization. With it, initialization runs once in the parent; children inherit the state via copy-on-write.

CmpLog: Solving Magic Bytes and Checksums

Coverage-guided fuzzing's Achilles heel: targets that check specific magic bytes, checksums, or magic numbers before reaching the interesting code.

void parse_packet(uint8_t *data, size_t len) {
    if (memcmp(data, "\xDE\xAD\xBE\xEF", 4) != 0) return;  // magic bytes
    if (crc32(data+4, len-8) != *(uint32_t*)(data+len-4)) return;  // checksum

    // Interesting parsing code never reached by random fuzzing
    parse_payload(data+4, len-8);
}

Without help, the fuzzer must randomly generate the 4-byte magic and a valid CRC. Probability: ~(1/256)^5. Effectively never.

CmpLog solves this by logging comparison operands during execution:

# Build CmpLog binary (separate from main fuzz binary)
afl-clang-fast -fsanitize=address cmplog_target.c -o target_cmplog

# Run with CmpLog
afl-fuzz -i seeds/ -o output/ \
    -l target_cmplog \    # CmpLog binary
    -- ./target_fuzz @@   # Main binary

AFL++ runs each input through both binaries. The CmpLog binary records every comparison operand. AFL++ then mutates inputs by substituting one comparison operand for the other — if data[0..3] was compared against 0xDEADBEEF and didn't match, try substituting 0xDEADBEEF into the input at that offset.

Result: magic bytes are found in seconds. Checksums require the additional redqueen mutation mode:

afl-fuzz -i seeds/ -o output/ \
    -l target_cmplog \
    -c 0 \              # Enable CmpLog pass
    -- ./target_fuzz @@

Redqueen extends CmpLog with feedback about which mutations to apply based on comparison patterns, solving the checksum problem without dictionaries.

Custom Mutators: Structure-Aware Fuzzing

AFL++ ships excellent generic mutators. For targets with specific input formats (JSON, protobuf, ASN.1, domain-specific protocols), custom mutators generate valid structure while fuzzing semantics.

The custom mutator API

// afl_custom.c — implement any subset of these functions

// Initialize: called once at startup
void *afl_custom_init(afl_state_t *afl, unsigned int seed) {
    MyMutatorState *state = malloc(sizeof(MyMutatorState));
    init_state(state, seed);
    return state;
}

// Core mutation: take input, produce mutated output
size_t afl_custom_fuzz(void *data, uint8_t **buf, size_t buf_size,
                       uint8_t **add_buf, size_t add_buf_size, size_t max_size) {
    MyMutatorState *state = (MyMutatorState *)data;

    // Parse current input as JSON
    JsonValue *json = json_parse(*buf, buf_size);
    if (!json) {
        // Fallback: return original input unmodified
        return buf_size;
    }

    // Apply structure-preserving mutation
    json_mutate_random_field(state, json);

    // Serialize back
    size_t out_len = json_serialize(json, *buf, max_size);
    json_free(json);
    return out_len;
}

// Optional: called to validate/trim corpus entries
uint8_t afl_custom_queue_get(void *data, const uint8_t *filename) {
    return 1;  // return 1 to accept, 0 to skip
}

// Cleanup
void afl_custom_deinit(void *data) {
    free(data);
}

Load the custom mutator:

AFL_CUSTOM_MUTATOR_LIBRARY=./afl_custom.so \
afl-fuzz -i seeds/ -o output/ -- ./target @@

Python custom mutators

For rapid prototyping, AFL++ supports Python mutators without compilation:

# custom_mutator.py
import json
import random

def init(seed):
    random.seed(seed)
    return {"rng": random.Random(seed)}

def fuzz(buf, add_buf, max_size):
    """Mutate buf and return mutated bytes."""
    try:
        data = json.loads(buf)
    except json.JSONDecodeError:
        return buf

    # Structure-aware mutation: modify a random field
    if isinstance(data, dict) and data:
        key = random.choice(list(data.keys()))

        # Apply type-appropriate mutation
        if isinstance(data[key], int):
            data[key] = random.choice([0, -1, 2**31-1, 2**32, -2**31, data[key]+1, data[key]-1])
        elif isinstance(data[key], str):
            mutations = ["", "A"*1000, "\x00\xff\x00", data[key] + "']};"]
            data[key] = random.choice(mutations)
        elif isinstance(data[key], list):
            data[key].append(None)

    return json.dumps(data).encode()

AFL_PYTHON_MODULE=custom_mutator \
AFL_CUSTOM_MUTATOR_ONLY=1 \
afl-fuzz -i seeds/ -o output/ -- ./target @@

AFL_CUSTOM_MUTATOR_ONLY=1 disables AFL++'s built-in mutations, using only the custom mutator. Remove this flag to stack custom mutations on top of built-in ones.

Grammar-based mutation with libAFL

For complex input languages (programming languages, protocol grammars), grammar-based mutation uses a formal grammar to generate valid inputs:

// libAFL grammar mutator (Rust)
use libafl::prelude::*;

fn main() {
    let grammar = json_grammar();  // Define JSON grammar
    let mutator = GrammarMutator::new(grammar);
    // ... rest of fuzzer setup
}

Grammar mutators guarantee syntactic validity, letting the fuzzer focus on semantic edge cases rather than syntax reconstruction.

QEMU Mode: Fuzzing Without Source Code

AFL++ can instrument binaries without source code using QEMU:

# Build QEMU support (one-time)
cd AFL++/qemu_mode && ./build_qemu_support.sh

# Fuzz a closed-source binary
afl-fuzz -Q -i seeds/ -o output/ -- ./closed_source_binary @@

QEMU mode patches the binary at runtime to record coverage. Slower than compile-time instrumentation (~2–5x slower) but enables fuzzing of:

Commercial software binaries
Firmware images
Libraries distributed as binaries

QEMU persistent mode recovers most of the speed penalty:

# QEMU persistent mode using function offsets
AFL_QEMU_PERSISTENT_ADDR=0x4008d0 \  # address of fuzz target function
AFL_ENTRYPOINT=0x4008d0 \
afl-fuzz -Q -i seeds/ -o output/ -- ./binary @@

Frida Mode: Instrumentation via Dynamic Hooking

For targets where QEMU doesn't work (iOS binaries, complex dynamic linking, custom instruction sets), AFL++ Frida mode instruments via the Frida dynamic instrumentation framework:

# Build Frida mode support
cd AFL++/frida_mode && make

# Fuzz with Frida instrumentation
afl-fuzz -O -i seeds/ -o output/ -- ./binary @@

Frida mode supports:

iOS binaries (via Frida's iOS support)
ARM binaries on x86 hosts
Complex binaries that don't work under QEMU

Coverage quality from Frida mode is comparable to QEMU mode, with better compatibility for complex binaries.

Parallel Fuzzing Configuration

AFL++ parallel fuzzing scales linearly with CPU count for most targets:

# Primary instance (generates new seeds)
afl-fuzz -M main -i seeds/ -o output/ -- ./target @@

# Secondary instances (explore from primary's corpus)
for i in {1..7}; do
    afl-fuzz -S worker_$i -i seeds/ -o output/ -- ./target @@ &
done

The -M (main) instance runs deterministic mutations. -S (secondary) instances run exploration-focused mutations. All instances share the output directory and read each other's findings.

For distributed fuzzing across multiple machines, sync the output directory via NFS, rsync, or a tool like afl-sync:

# On each machine, after local fuzzing:
rsync -az output/ remote_host:/shared/output/

# Periodically pull remote findings
rsync -az remote_host:/shared/output/ output/

Power Schedule Selection

AFL++ ships multiple power schedules. Choose based on your target:

# Default: fast
afl-fuzz -p fast -i seeds/ -o output/ -- ./target @@

# Explore: better for targets with hard-to-reach coverage
afl-fuzz -p explore -i seeds/ -o output/ -- ./target @@

# Exploit: if you've found crashes and want to find variants
afl-fuzz -p exploit -i seeds/ -o output/ -- ./target @@

# Rare: focuses on least-covered paths
afl-fuzz -p rare -i seeds/ -o output/ -- ./target @@

For systematic comparison: run multiple instances with different schedules and compare coverage after 24 hours.

Environment Variables for Fine-Tuning

AFL++ exposes extensive configuration via environment variables:

# Increase bitmap size for complex targets with many edges
AFL_MAP_SIZE=10000000 afl-fuzz ...

# Skip deterministic mutations (faster for large seeds)
AFL_SKIP_DETERMINISTIC=1 afl-fuzz ...

# Disable trimming (faster, worse corpus quality)
AFL_NO_TRIM=1 afl-fuzz ...

# Ignore timeouts on startup (for slow-starting targets)
AFL_SKIP_CRASHES=1 afl-fuzz ...

# Enable CmpLog without a separate CmpLog binary (compile-time)
AFL_LLVM_CMPLOG=1 afl-clang-fast ...

Measuring AFL++ Effectiveness

AFL++ provides comprehensive stats in output/fuzzer_stats:

execs_per_sec   : 45231   # current throughput
corpus_count    : 2847    # corpus entries
bitmap_cvg      : 14.23%  # % of map bytes touched
unique_crashes  : 12      # deduped crashes

Watch for:

execs_per_sec below 1,000: performance problem (slow target, missing persistent mode)
bitmap_cvg plateau before 20%: likely missed coverage (custom mutator or CmpLog needed)
corpus_count > 100,000: run afl-cmin to minimize

Summary

Basic AFL++ finds bugs. Advanced AFL++ finds more bugs, faster:

Persistent mode: 10–40x throughput improvement for in-process targets
CmpLog: breaks through magic bytes and checksums that block random fuzzing
Custom mutators: structure-aware mutation for format-specific targets
QEMU/Frida modes: coverage instrumentation without source code

Start with persistent mode and CmpLog — they work for most targets with minimal code changes. Add custom mutators when you see coverage plateauing in format-specific parsing code.
