TLS/SSL Testing Guide: testssl.sh, sslyze & Certificate Validation

HelpMeTest

18 May 2026 — 7 min read

TLS misconfiguration is one of the most common and consequential security issues in web applications. Weak cipher suites, expired certificates, deprecated protocol versions, and missing HSTS — these issues are easy to find with the right tools and easy to automate in CI. This guide covers the full TLS/SSL testing workflow.

What TLS Testing Covers

A complete TLS test validates:

Protocol versions — TLS 1.2 and 1.3 should be the only supported versions; TLS 1.0, 1.1, and SSLv3 must be disabled
Cipher suites — weak ciphers (RC4, 3DES, export ciphers) must be disabled; forward secrecy (ECDHE) required
Certificate chain — certificates must be valid, not expired, signed by a trusted CA, and have a complete chain
Key size — RSA keys ≥ 2048 bits, EC keys ≥ 256 bits
Security headers — HSTS, HSTS preloading
Known vulnerabilities — BEAST, POODLE, HEARTBLEED, ROBOT, DROWN, LOGJAM

testssl.sh

testssl.sh is the most comprehensive open-source TLS scanner. It tests everything and produces a clear pass/warn/fail report.

Installation

# Clone and run directly
git clone --depth 1 https://github.com/drwetter/testssl.sh.git
cd testssl.sh

# Docker (recommended for CI)
docker pull drwetter/testssl.sh

Basic Scan

./testssl.sh https://staging.example.com

# Docker
docker run --rm drwetter/testssl.sh https://staging.example.com

Output example:

Testing protocols via sockets except NPN+ALPN
 SSLv2      not offered (OK)
 SSLv3      not offered (OK)
 TLS 1      not offered (OK)
 TLS 1.1    not offered (OK)
 TLS 1.2    offered (OK)
 TLS 1.3    offered (OK)

Testing cipher categories
 NULL ciphers (no encryption)                  not offered (OK)
 Anonymous NULL Ciphers (no authentication)    not offered (OK)
 Export ciphers (w/o ADH+NULL)                 not offered (OK)
 LOW: 64 Bit + DES, RC[2,4], MD5 (w/o export) not offered (OK)
 Triple DES Ciphers / IDEA                     not offered (OK)
 Obsoleted CBC ciphers (AES, CAMELLIA, ARIA)   not offered (OK)
 Strong encryption (AEAD ciphers)              offered (OK)

Testing vulnerabilities
 Heartbleed (CVE-2014-0160)                    not vulnerable (OK)
 CCS (CVE-2014-0224)                           not vulnerable (OK)
 POODLE, SSL (CVE-2014-3566)                   not vulnerable (OK)
 ROBOT                                         not vulnerable (OK)

Output Formats for CI

# JSON output for parsing
./testssl.sh --jsonfile results.json https://staging.example.com

# CSV for spreadsheets
./testssl.sh --csvfile results.csv https://staging.example.com

# HTML report
./testssl.sh --htmlfile results.html https://staging.example.com

# Log file
./testssl.sh --logfile results.log https://staging.example.com

Testing Specific Areas

# Protocol support only
./testssl.sh --protocols https://staging.example.com

# Cipher suites only
./testssl.sh --cipher-per-proto https://staging.example.com

# Certificate only
./testssl.sh --server-certificate https://staging.example.com

# Vulnerabilities only
./testssl.sh --vulnerabilities https://staging.example.com

# Security headers
./testssl.sh --headers https://staging.example.com

# Everything, including client simulation
./testssl.sh --full https://staging.example.com

Testing Internal Services

For services not publicly accessible:

# Test by IP
./testssl.sh 10.0.0.50:8443

# Test with explicit SNI (Server Name Indication)
./testssl.sh --sni staging.internal.example.com 10.0.0.50:443

# Disable certificate verification for self-signed certs in dev
./testssl.sh --insecure https://staging.internal.example.com

sslyze

sslyze is a Python-based TLS scanner with structured JSON output that's easier to parse in scripts.

Installation

pip install sslyze

Command-Line Usage

# Full scan
sslyze staging.example.com

# Scan multiple hosts
sslyze staging.example.com api.staging.example.com

# JSON output
sslyze --json_out results.json staging.example.com

# Specific modules
sslyze --tlsv1 --tlsv1_1 --heartbleed --robot staging.example.com

Python API

sslyze has a clean Python API for programmatic use:

import json
from sslyze import Scanner, ServerScanRequest, ScanCommand
from sslyze.errors import ServerHostnameCouldNotBeResolved

def scan_tls(hostname: str, port: int = 443) -> dict:
    """Scan TLS configuration and return findings."""

    scanner = Scanner()

    # Request all scan commands
    request = ServerScanRequest(
        server_location=ServerNetworkLocation(hostname=hostname, port=port),
        scan_commands={
            ScanCommand.SSL_2_0_CIPHER_SUITES,
            ScanCommand.SSL_3_0_CIPHER_SUITES,
            ScanCommand.TLS_1_0_CIPHER_SUITES,
            ScanCommand.TLS_1_1_CIPHER_SUITES,
            ScanCommand.TLS_1_2_CIPHER_SUITES,
            ScanCommand.TLS_1_3_CIPHER_SUITES,
            ScanCommand.CERTIFICATE_INFO,
            ScanCommand.HEARTBLEED,
            ScanCommand.ROBOT,
            ScanCommand.HTTP_HEADERS,
        },
    )

    scanner.queue_scans([request])

    findings = {
        'hostname': hostname,
        'issues': [],
        'passed': True
    }

    for result in scanner.get_results():
        if result.scan_status == ServerScanStatusEnum.ERROR_NO_CONNECTIVITY:
            findings['issues'].append(f'Could not connect to {hostname}:{port}')
            findings['passed'] = False
            continue

        # Check deprecated protocols
        for protocol, command in [
            ('SSLv2', ScanCommand.SSL_2_0_CIPHER_SUITES),
            ('SSLv3', ScanCommand.SSL_3_0_CIPHER_SUITES),
            ('TLS 1.0', ScanCommand.TLS_1_0_CIPHER_SUITES),
            ('TLS 1.1', ScanCommand.TLS_1_1_CIPHER_SUITES),
        ]:
            scan_result = result.scan_result.__dict__.get(command.value.lower().replace('.', '_'))
            if scan_result and scan_result.accepted_cipher_suites:
                findings['issues'].append(f'{protocol} is supported — must be disabled')
                findings['passed'] = False

        # Check certificate
        cert_result = result.scan_result.certificate_info
        if cert_result:
            for deployment in cert_result.certificate_deployments:
                if not deployment.verified_certificate_chain:
                    findings['issues'].append('Certificate chain incomplete or untrusted')
                    findings['passed'] = False

                # Check expiry
                leaf_cert = deployment.received_certificate_chain[0]
                from datetime import datetime, timezone
                expires = leaf_cert.not_valid_after_utc
                days_until_expiry = (expires - datetime.now(timezone.utc)).days
                if days_until_expiry < 30:
                    findings['issues'].append(f'Certificate expires in {days_until_expiry} days')
                    findings['passed'] = False

        # Check Heartbleed
        heartbleed = result.scan_result.heartbleed
        if heartbleed and heartbleed.is_vulnerable_to_heartbleed:
            findings['issues'].append('Vulnerable to Heartbleed (CVE-2014-0160)')
            findings['passed'] = False

        # Check ROBOT
        robot = result.scan_result.robot
        if robot and robot.robot_result.value in ('VULNERABLE_STRONG_ORACLE', 'VULNERABLE_WEAK_ORACLE'):
            findings['issues'].append('Vulnerable to ROBOT attack')
            findings['passed'] = False

        # Check HSTS
        headers = result.scan_result.http_headers
        if headers and not headers.strict_transport_security_header:
            findings['issues'].append('HSTS header missing')
            # Not a hard fail — warn only

    return findings


if __name__ == '__main__':
    import sys
    hostname = sys.argv[1] if len(sys.argv) > 1 else 'example.com'
    result = scan_tls(hostname)
    print(json.dumps(result, indent=2))
    sys.exit(0 if result['passed'] else 1)

Certificate Validation Testing

Manual Certificate Checks

# View certificate details
openssl s_client -connect staging.example.com:443 -servername staging.example.com \
  </dev/null 2>/dev/null | openssl x509 -noout -text

# Check expiry
openssl s_client -connect staging.example.com:443 \
  </dev/null 2>/dev/null | openssl x509 -noout -dates

# Check the full chain
openssl s_client -connect staging.example.com:443 \
  -showcerts </dev/null 2>/dev/null

# Verify against system trust store
openssl s_client -connect staging.example.com:443 \
  -verify_return_error </dev/null

# Check SANs (Subject Alternative Names)
openssl s_client -connect staging.example.com:443 \
  </dev/null 2>/dev/null | openssl x509 -noout -ext subjectAltName

Certificate Expiry Monitoring

#!/bin/bash
# check-cert-expiry.sh — alerts if cert expires within N days

HOSTS=(
  "staging.example.com:443"
  "api.staging.example.com:443"
  "internal.example.com:8443"
)

WARN_DAYS=30
CRITICAL_DAYS=7

for HOST_PORT in "${HOSTS[@]}"; do
  HOST="${HOST_PORT%%:*}"
  PORT="${HOST_PORT##*:}"

  EXPIRY=$(openssl s_client -connect "$HOST_PORT" -servername "$HOST" \
    </dev/null 2>/dev/null | openssl x509 -noout -enddate | cut -d= -f2)

  EXPIRY_EPOCH=$(date -d "$EXPIRY" +%s 2>/dev/null || date -j -f "%b %d %T %Y %Z" "$EXPIRY" +%s)
  NOW_EPOCH=$(date +%s)
  DAYS_REMAINING=$(( (EXPIRY_EPOCH - NOW_EPOCH) / 86400 ))

  if [ "$DAYS_REMAINING" -lt "$CRITICAL_DAYS" ]; then
    echo "CRITICAL: $HOST cert expires in $DAYS_REMAINING days ($EXPIRY)"
    exit 2
  elif [ "$DAYS_REMAINING" -lt "$WARN_DAYS" ]; then
    echo "WARNING: $HOST cert expires in $DAYS_REMAINING days ($EXPIRY)"
  else
    echo "OK: $HOST cert valid for $DAYS_REMAINING days"
  fi
done

Cipher Suite Testing

Testing Specific Cipher Suites

# List all accepted ciphers on TLS 1.2
nmap --script ssl-enum-ciphers -p 443 staging.example.com

# Test if a specific weak cipher is supported
openssl s_client -connect staging.example.com:443 \
  -cipher "DES-CBC3-SHA" 2>&1 | grep -E "(CONNECTED|handshake failure)"

# Test RC4 (should fail)
openssl s_client -connect staging.example.com:443 \
  -cipher "RC4-SHA" 2>&1 | grep -E "(CONNECTED|handshake failure)"

# Verify forward secrecy (ECDHE should be in cipher)
openssl s_client -connect staging.example.com:443 \
  </dev/null 2>/dev/null | grep "Cipher is"

Cipher Suite Benchmarking

# Test supported cipher list with testssl.sh
./testssl.sh --cipher-per-proto staging.example.com

# Check for weak ciphers to reject
./testssl.sh --cipher-per-proto staging.example.com 2>/dev/null | grep -E "(MEDIUM|WEAK|NULL)"

Cipher suites to verify are not offered:

RC4 — broken, biased keystream
3DES / DES-CBC3 — SWEET32 attack (birthday attack on 64-bit blocks)
NULL encryption — no encryption at all
EXPORT ciphers — deliberately weakened for export compliance (now exploitable)
DH < 2048 bits — Logjam vulnerable
ANON — no authentication

Cipher suites to verify are offered:

ECDHE-*-AES*-GCM-SHA* — AEAD, forward secrecy
TLS_AES_256_GCM_SHA384 — TLS 1.3
TLS_CHACHA20_POLY1305_SHA256 — TLS 1.3

CI/CD Integration

GitHub Actions with testssl.sh

name: TLS Security Check

on:
  push:
    branches: [main]
  schedule:
    - cron: '0 6 * * *'  # Daily certificate expiry check

jobs:
  tls-check:
    runs-on: ubuntu-latest

    steps:
      - name: Checkout
        uses: actions/checkout@v4

      - name: Run testssl.sh
        run: |
          docker run --rm drwetter/testssl.sh \
            --jsonfile /tmp/tls-results.json \
            --quiet \
            ${{ vars.STAGING_URL }}

      - name: Parse results
        run: |
          # Fail on HIGH or CRITICAL findings
          FAILURES=$(cat /tmp/tls-results.json | \
            jq -r '.[] | select(.severity == "HIGH" or .severity == "CRITICAL") | "\(.severity): \(.id) - \(.finding)"')

          if [ -n "$FAILURES" ]; then
            echo "TLS issues found:"
            echo "$FAILURES"
            exit 1
          fi

          echo "TLS check passed"

      - name: Upload TLS report
        uses: actions/upload-artifact@v4
        if: always()
        with:
          name: tls-report
          path: /tmp/tls-results.json

Pre-Deployment Gate

Add to your deployment pipeline to block deployments when TLS config regresses:

#!/bin/bash
# tls-gate.sh

TARGET="$1"

echo "Running TLS check for $TARGET..."

# Run sslyze and save JSON
sslyze --json_out /tmp/sslyze-results.json "$TARGET" > /dev/null 2>&1

# Check for critical issues
python3 - <<'EOF'
import json, sys

with open('/tmp/sslyze-results.json') as f:
    results = json.load(f)

failures = []

for result in results.get('server_scan_results', []):
    scan = result.get('scan_result', {})

    # Check deprecated protocols
    for proto in ['ssl_2_0_cipher_suites', 'ssl_3_0_cipher_suites', 'tls_1_0_cipher_suites', 'tls_1_1_cipher_suites']:
        if scan.get(proto, {}).get('accepted_cipher_suites'):
            failures.append(f'Deprecated protocol supported: {proto}')

    # Check Heartbleed
    if scan.get('heartbleed', {}).get('is_vulnerable_to_heartbleed'):
        failures.append('Vulnerable to Heartbleed')

    # Check certificate
    for deployment in scan.get('certificate_info', {}).get('certificate_deployments', []):
        if not deployment.get('verified_certificate_chain'):
            failures.append('Invalid certificate chain')

if failures:
    print('TLS FAILURES:')
    for f in failures:
        print(f'  - {f}')
    sys.exit(1)

print('TLS check: PASSED')
sys.exit(0)
EOF

Common TLS Issues and Fixes

Issue	Risk	Fix
TLS 1.0/1.1 enabled	POODLE, BEAST	Set `ssl_protocols TLSv1.2 TLSv1.3;` in nginx
RC4/3DES ciphers	Data decryption	Remove from `ssl_ciphers` config
Missing HSTS	Downgrade attacks	Add `Strict-Transport-Security: max-age=31536000`
Self-signed certificate in prod	MitM attacks	Use Let's Encrypt or a trusted CA
Certificate expiry	Service outage	Automate renewal (Let's Encrypt + certbot)
Weak DH parameters	Logjam	Generate strong DH params: `openssl dhparam -out dhparam.pem 2048`
Missing OCSP stapling	Performance, privacy	Enable in nginx with `ssl_stapling on`

Nginx TLS Configuration Reference

A configuration that passes all major TLS tests:

server {
    listen 443 ssl http2;
    server_name example.com;

    ssl_certificate /etc/ssl/certs/example.com.crt;
    ssl_certificate_key /etc/ssl/private/example.com.key;

    # Only TLS 1.2 and 1.3
    ssl_protocols TLSv1.2 TLSv1.3;

    # Strong cipher suites with forward secrecy
    ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305:DHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES256-GCM-SHA384;
    ssl_prefer_server_ciphers off;

    # HSTS — 1 year, including subdomains
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload" always;

    # OCSP stapling
    ssl_stapling on;
    ssl_stapling_verify on;
    ssl_trusted_certificate /etc/ssl/certs/chain.pem;
    resolver 8.8.8.8 8.8.4.4 valid=300s;

    # DH parameters for DHE ciphers
    ssl_dhparam /etc/nginx/dhparam.pem;

    # Session management
    ssl_session_timeout 1d;
    ssl_session_cache shared:MozSSL:10m;
    ssl_session_tickets off;
}

Test this configuration gets an A+ on SSL Labs before deploying to production.

TLS/SSL Testing Guide: testssl.sh, sslyze & Certificate Validation

HelpMeTest

What TLS Testing Covers

testssl.sh

Installation

Basic Scan

Output Formats for CI

Testing Specific Areas

Testing Internal Services

sslyze

Installation

Command-Line Usage

Python API

Certificate Validation Testing

Manual Certificate Checks

Certificate Expiry Monitoring

Cipher Suite Testing

Testing Specific Cipher Suites

Cipher Suite Benchmarking

CI/CD Integration

GitHub Actions with testssl.sh

Pre-Deployment Gate

Common TLS Issues and Fixes

Nginx TLS Configuration Reference

Read more

Test Result Reporting and Failing Fast in CI Pipelines

SOC 2 Evidence Collection Automation: Stop Emailing Screenshots to Your Auditor

PCI-DSS 4.0 Penetration Testing: Scoping, Methodology, and What Assessors Actually Check

Data Pipeline CI/CD Testing: Automate Quality Gates
