Synthetic Monitoring and Canary Deployments with Datadog and Grafana

# datadog_synthetics.tf
resource "datadog_synthetics_test" "api_health_check" {
  name    = "API Health Check - Global"
  type    = "api"
  subtype = "http"
  status  = "live"

  request_definition {
    method = "GET"
    url    = "https://api.yourservice.com/health"
  }

  request_headers = {
    "Accept"       = "application/json"
    "X-Synthetic"  = "true"  # Tag synthetic traffic in your logs
  }

  assertion {
    type     = "statusCode"
    operator = "is"
    target   = "200"
  }

  assertion {
    type     = "responseTime"
    operator = "lessThan"
    target   = "2000"  # 2 seconds
  }

  assertion {
    type     = "body"
    operator = "contains"
    target   = "\"status\":\"ok\""
  }

  options_list {
    tick_every       = 60   # Run every 60 seconds
    min_failure_duration = 60   # Alert if failing for 60+ seconds
    min_location_failed  = 2    # Alert if 2+ locations fail

    retry {
      count    = 2
      interval = 1000  # Retry after 1 second
    }
  }

  locations = [
    "aws:us-east-1",
    "aws:eu-west-1",
    "aws:ap-southeast-1"
  ]

  message = "@pagerduty-api-critical API health check failing in {{#is_recovery}}recovered in{{/is_recovery}}{{#is_alert}}failed from{{/is_alert}} {{location}}"
}

# Multi-step API test for checkout flow
resource "datadog_synthetics_test" "checkout_flow" {
  name    = "E2E Checkout Flow"
  type    = "api"
  subtype = "multi"
  status  = "live"

  api_step {
    name = "Get products"
    subtype = "http"

    request_definition {
      method = "GET"
      url    = "https://api.yourservice.com/products"
    }

    assertion {
      type     = "statusCode"
      operator = "is"
      target   = "200"
    }

    extracted_value {
      name  = "product_id"
      type  = "body"
      field = "$.data[0].id"
    }
  }

  api_step {
    name = "Add to cart"
    subtype = "http"

    request_definition {
      method = "POST"
      url    = "https://api.yourservice.com/cart"
      body   = "{\"product_id\": \"{{ product_id }}\", \"quantity\": 1}"
    }

    assertion {
      type     = "statusCode"
      operator = "is"
      target   = "201"
    }

    extracted_value {
      name  = "cart_id"
      type  = "body"
      field = "$.cart_id"
    }
  }

  api_step {
    name = "Checkout"
    subtype = "http"

    request_definition {
      method = "POST"
      url    = "https://api.yourservice.com/checkout/{{ cart_id }}"
    }

    assertion {
      type     = "statusCode"
      operator = "is"
      target   = "200"
    }
  }

  options_list {
    tick_every = 300  # Every 5 minutes
  }

  locations = ["aws:us-east-1", "aws:eu-west-1"]
}

# Using Datadog's Python client to create browser tests
from datadog_api_client import ApiClient, Configuration
from datadog_api_client.v1.api.synthetics_api import SyntheticsApi
from datadog_api_client.v1.model.synthetics_browser_test import SyntheticsBrowserTest

configuration = Configuration()
with ApiClient(configuration) as api_client:
    api_instance = SyntheticsApi(api_client)

    body = SyntheticsBrowserTest(
        name="Login Flow - Chrome",
        type="browser",
        config={
            "request": {
                "url": "https://app.yourservice.com/login"
            }
        },
        steps=[
            {
                "name": "Enter email",
                "type": "typeText",
                "params": {
                    "element": {"userLocator": {"values": [{"type": "css", "value": "#email"}]}},
                    "value": "test@example.com"
                }
            },
            {
                "name": "Enter password",
                "type": "typeText",
                "params": {
                    "element": {"userLocator": {"values": [{"type": "css", "value": "#password"}]}},
                    "value": "{{ synthetics.SYNTHETIC_PASSWORD }}"  # Use Datadog secret
                }
            },
            {
                "name": "Click login",
                "type": "click",
                "params": {
                    "element": {"userLocator": {"values": [{"type": "css", "value": "button[type=submit]"}]}}
                }
            },
            {
                "name": "Assert dashboard loaded",
                "type": "assertElementContent",
                "params": {
                    "element": {"userLocator": {"values": [{"type": "css", "value": "h1.dashboard-title"}]}},
                    "operator": "contains",
                    "value": "Dashboard"
                }
            }
        ],
        options={
            "tick_every": 3600,  # Every hour
            "device_ids": ["chrome.laptop_large"]
        },
        locations=["aws:us-east-1"],
        status="live"
    )

    result = api_instance.create_synthetics_browser_test(body=body)

// k6 synthetic script for Grafana Cloud
import { browser } from 'k6/experimental/browser';
import { check, sleep } from 'k6';
import http from 'k6/http';

export const options = {
  scenarios: {
    api_check: {
      executor: 'constant-arrival-rate',
      rate: 1,
      timeUnit: '1m',  // 1 request per minute
      duration: '8760h',  // Run indefinitely
      preAllocatedVUs: 2,
    },
  },
  thresholds: {
    http_req_failed: ['rate<0.01'],
    http_req_duration: ['p(95)<500'],
  },
};

export default function () {
  const response = http.get('https://api.yourservice.com/health', {
    headers: { 'X-Synthetic': 'grafana-k6' }
  });

  check(response, {
    'status is 200': (r) => r.status === 200,
    'response time OK': (r) => r.timings.duration < 500,
    'body contains status ok': (r) => r.body.includes('"status":"ok"'),
  });
}

# argo-rollout.yaml
apiVersion: argoproj.io/v1alpha1
kind: Rollout
metadata:
  name: api-service
spec:
  strategy:
    canary:
      steps:
        - setWeight: 5      # 5% canary
        - pause: {duration: 2m}
        - analysis:
            templates:
              - templateName: synthetic-health-check
        - setWeight: 25     # 25% after passing synthetics
        - pause: {duration: 5m}
        - analysis:
            templates:
              - templateName: synthetic-health-check
        - setWeight: 100    # Full rollout
---
apiVersion: argoproj.io/v1alpha1
kind: AnalysisTemplate
metadata:
  name: synthetic-health-check
spec:
  metrics:
    - name: datadog-synthetic-results
      interval: 1m
      count: 5    # Check 5 times
      successCondition: result.status == "passed"
      failureLimit: 1  # Rollback on first failure

      provider:
        datadog:
          query: |
            avg:synthetics.test_runs{status:failed,test_name:API Health Check}.as_count() == 0

import subprocess
import time
import requests

def deploy_with_synthetic_gate(image_tag: str, synthetic_test_id: str) -> bool:
    """
    Deploy new image with synthetic monitoring gate.
    Returns True if deployment succeeded, False if rolled back.
    """
    print(f"Deploying {image_tag}...")

    # Deploy canary (5%)
    subprocess.run([
        "kubectl", "set", "image",
        "deployment/api-service-canary",
        f"api-service={image_tag}"
    ], check=True)

    print("Waiting 2 minutes for canary to stabilize...")
    time.sleep(120)

    # Check synthetic test results for the past 2 minutes
    dd_api = DatadogSyntheticsClient()
    results = dd_api.get_test_results(
        test_id=synthetic_test_id,
        from_time=time.time() - 120
    )

    failed_results = [r for r in results if r["result"]["passed"] is False]

    if len(failed_results) > 0:
        print(f"❌ Synthetic tests failing ({len(failed_results)} failures). Rolling back.")
        subprocess.run([
            "kubectl", "rollout", "undo",
            "deployment/api-service-canary"
        ], check=True)
        return False

    print("✅ Synthetics passing. Promoting to full rollout.")
    subprocess.run([
        "kubectl", "set", "image",
        "deployment/api-service",
        f"api-service={image_tag}"
    ], check=True)

    return True

# Alert on synthetic failures in Grafana Alerting
alert_rule = {
    "title": "Synthetic Monitor Failure",
    "condition": "C",
    "data": [
        {
            "refId": "A",
            "datasourceUid": "prometheus",
            "model": {
                "expr": 'probe_success{job="blackbox"} == 0',
                "intervalMs": 10000,
                "maxDataPoints": 43200
            }
        },
        {
            "refId": "C",
            "datasourceUid": "__expr__",
            "model": {
                "type": "threshold",
                "conditions": [{
                    "evaluator": {"params": [0], "type": "gt"},
                    "operator": {"type": "and"},
                    "query": {"params": ["A"]},
                    "reducer": {"params": [], "type": "last"}
                }]
            }
        }
    ],
    "for": "5m",  # Must fail for 5 minutes before alerting
    "labels": {"severity": "critical"},
    "annotations": {
        "summary": "Synthetic monitor {{ $labels.instance }} is failing",
        "description": "The synthetic monitor has been failing for 5 minutes. Check the endpoint immediately."
    }
}

def get_synthetic_availability(test_id: str, window_days: int = 28) -> float:
    """
    Calculate availability SLI from synthetic monitor data.
    Returns fraction of successful checks in the window.
    """
    results = dd_client.get_all_test_results(
        test_id=test_id,
        from_time=time.time() - (window_days * 86400)
    )

    total = len(results)
    passed = sum(1 for r in results if r["result"]["passed"])

    return passed / total if total > 0 else 1.0

# Check SLO compliance
sli_value = get_synthetic_availability("abc-123-def", window_days=28)
slo_target = 0.999

if sli_value < slo_target:
    error_minutes = (slo_target - sli_value) * 28 * 24 * 60
    print(f"SLO BREACH: Synthetic availability {sli_value:.4%} below {slo_target:.4%}")
    print(f"  Excess downtime: {error_minutes:.1f} minutes")
