SonarQube Pull Request Decoration: Inline Code Analysis on Every PR

How PR Decoration Works

1. CI runs SonarQube analysis on the PR branch
2. SonarQube compares changed code against the target branch baseline
3. SonarQube posts a status check to the PR (pass/fail based on quality gate)
4. SonarQube adds inline comments on lines with new issues
5. Reviewers see issues without switching to the SonarQube UI

GitHub Integration Setup

Step 1: Create a GitHub App or Personal Access Token

For GitHub Apps (recommended for organizations):

1. In GitHub, go to Settings → Developer settings → GitHub Apps → New GitHub App
2. Set permissions: Pull requests (Read & Write), Commit statuses (Read & Write)
3. Generate a private key and download it

For Personal Access Token (simpler for small teams):

1. GitHub → Settings → Developer settings → Personal access tokens
2. Required scopes: repo (full), read:org

Step 2: Configure ALM in SonarQube

Administration → ALM Integrations → GitHub:

Configuration name: GitHub
App ID: <your-github-app-id>
Client ID: <oauth-client-id>
Client Secret: <oauth-client-secret>
Private Key: <contents-of-private-key.pem>

Or for PAT-based setup:

Personal Access Token: <your-token>

Step 3: Link Your Project to the GitHub Repository

In your SonarQube project → Project Settings → General Settings → ALM Integration:

• ALM: GitHub
• Repository name: owner/repo-name

Step 4: Configure Your CI

GitHub Actions example:

name: SonarQube Analysis
on:
  pull_request:
    types: [opened, synchronize, reopened]

jobs:
  sonarqube:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
        with:
          fetch-depth: 0  # Required for SonarQube blame analysis

      - name: SonarQube Scan
        uses: SonarSource/sonarqube-scan-action@master
        env:
          SONAR_TOKEN: ${{ secrets.SONAR_TOKEN }}
          SONAR_HOST_URL: ${{ secrets.SONAR_HOST_URL }}
        with:
          args: >
            -Dsonar.pullrequest.key=${{ github.event.pull_request.number }}
            -Dsonar.pullrequest.branch=${{ github.head_ref }}
            -Dsonar.pullrequest.base=${{ github.base_ref }}
            -Dsonar.pullrequest.github.repository=${{ github.repository }}

Step 5: Verify

Open a pull request. Within a few minutes:

• A status check appears on the PR (SonarQube/Quality Gate)
• Inline comments appear on lines with new issues
• A summary comment shows issue count, coverage delta, and quality gate result

GitLab Integration

Create a GitLab Access Token

Settings → Access Tokens → Create token with api scope.

Configure in SonarQube

Administration → ALM Integrations → GitLab:

Configuration name: GitLab
GitLab URL: https://gitlab.com (or your self-hosted instance)
Personal Access Token: <your-token>

CI Configuration (GitLab CI)

sonarqube-check:
  stage: test
  image:
    name: sonarsource/sonar-scanner-cli:latest
    entrypoint: [""]
  variables:
    SONAR_USER_HOME: "${CI_PROJECT_DIR}/.sonar"
    GIT_DEPTH: "0"
  script:
    - sonar-scanner
      -Dsonar.projectKey=${CI_PROJECT_PATH_SLUG}
      -Dsonar.sources=.
      -Dsonar.host.url=${SONAR_HOST_URL}
      -Dsonar.login=${SONAR_TOKEN}
      -Dsonar.pullrequest.key=${CI_MERGE_REQUEST_IID}
      -Dsonar.pullrequest.branch=${CI_MERGE_REQUEST_SOURCE_BRANCH_NAME}
      -Dsonar.pullrequest.base=${CI_MERGE_REQUEST_TARGET_BRANCH_NAME}
  only:
    - merge_requests

Configuring What Gets Decorated

Only Fail on New Issues

The default behavior is correct: only new code (introduced in the PR) is evaluated. Don't change this unless you have a specific reason.

# sonar-project.properties
sonar.qualitygate.wait=true  # Fail the CI build if quality gate fails

Customize the Quality Gate for PRs

Create a separate quality gate for PRs in Administration → Quality Gates:

• Conditions: Only on new code
• Coverage on new code ≥ 80%
• Duplicated lines on new code < 3%
• New bugs = 0
• New vulnerabilities = 0

Assign this quality gate to your project.

Suppress Decoration Noise

If you're getting too many inline comments from legacy code in the PR:

# Exclude test files from new code policy
sonar.coverage.exclusions=**/*Test.java,**/*Spec.js
sonar.cpd.exclusions=**/*Test.java

Troubleshooting

Status check doesn't appear: Check that sonar.pullrequest.key is set correctly. For GitHub, this should be the PR number (integer).

Comments appear on wrong lines: Use fetch-depth: 0 in your checkout step. SonarQube needs full git history for accurate blame analysis.

Quality gate always passes: Check if you're using Community Edition (which doesn't support branch analysis). The quality gate applies to the full project, not just the PR diff.

Decoration works but coverage delta is wrong: Ensure coverage reports are being imported with sonar.coverage.jacoco.xmlReportPaths (Java) or sonar.javascript.lcov.reportPaths (JS).

PR decoration turns SonarQube from a dashboard you check occasionally into a gatekeeper you can't ignore. New issues surface in the review workflow, before they reach the main branch.
