OpenTelemetry with Playwright: E2E Testing with Full Observability

Playwright tests verify what the user sees. OpenTelemetry traces verify what the backend did to produce it. Together, they give you the most complete picture of correctness available: from browser click to database write.

The Architecture

Playwright test
    → browser action (click, form fill)
    → HTTP request to your API
    → [service A → service B → DB]
         spans emitted to Jaeger
    → Playwright asserts on UI outcome
    → Test also asserts on trace content

One test, two dimensions of correctness.

Setup

You need:

  1. Playwright installed (npm install -D @playwright/test)
  2. Your app instrumented with OpenTelemetry
  3. Jaeger running locally or in CI
# Start Jaeger
docker run -d --name jaeger \
  -e COLLECTOR_OTLP_ENABLED=<span class="hljs-literal">true \
  -p 16686:16686 -p 4318:4318 \
  jaegertracing/all-in-one:latest

<span class="hljs-comment"># Install Playwright
npm install -D @playwright/test
npx playwright install chromium

Creating a Jaeger Query Helper

// tests/helpers/jaeger.js
const JAEGER = 'http://localhost:16686/api';

async function findTrace(service, operation, afterMs) {
  const params = new URLSearchParams({
    service,
    operation,
    start: (afterMs * 1000).toString(),
    limit: '5',
  });

  // Retry up to 5 times (traces export asynchronously)
  for (let i = 0; i < 5; i++) {
    const res = await fetch(`${JAEGER}/traces?${params}`);
    const json = await res.json();
    if (json.data && json.data.length > 0) return json.data[0];
    await new Promise(r => setTimeout(r, 500));
  }
  throw new Error(`No trace found for ${service} ${operation} after ${afterMs}`);
}

function analyzeTrace(trace) {
  const processMap = {};
  Object.entries(trace.processes).forEach(([k, v]) => {
    processMap[k] = v.serviceName;
  });

  return {
    spans: trace.spans.map(s => ({
      operation: s.operationName,
      service: processMap[s.processID],
      durationMs: s.duration / 1000,
      hasError: s.tags.some(t => t.key === 'error' && t.value),
      tags: Object.fromEntries(s.tags.map(t => [t.key, t.value])),
    })),
    get services() { return [...new Set(this.spans.map(s => s.service))]; },
    get hasErrors() { return this.spans.some(s => s.hasError); },
  };
}

module.exports = { findTrace, analyzeTrace };

Writing a Playwright + OpenTelemetry Test

// tests/checkout.spec.js
const { test, expect } = require('@playwright/test');
const { findTrace, analyzeTrace } = require('./helpers/jaeger');

test('checkout flow — UI success and backend trace correctness', async ({ page }) => {
  const startMs = Date.now();

  // Step 1: Navigate and add item to cart
  await page.goto('http://localhost:3000');
  await page.click('[data-testid="product-A"]');
  await page.click('[data-testid="add-to-cart"]');
  await expect(page.locator('[data-testid="cart-count"]')).toHaveText('1');

  // Step 2: Go to checkout
  await page.click('[data-testid="checkout-btn"]');
  await page.fill('[data-testid="card-number"]', '4111111111111111');
  await page.fill('[data-testid="card-expiry"]', '12/26');
  await page.fill('[data-testid="card-cvv"]', '123');

  // Step 3: Submit order
  await page.click('[data-testid="place-order-btn"]');
  await expect(page.locator('[data-testid="order-confirmation"]')).toBeVisible();
  const orderId = await page.locator('[data-testid="order-id"]').textContent();

  // Step 4: Assert UI outcome
  expect(orderId).toMatch(/^ORD-\d+$/);

  // Step 5: Assert on backend trace
  const trace = analyzeTrace(await findTrace('order-service', 'POST /orders', startMs));

  // All services participated
  expect(trace.services).toEqual(
    expect.arrayContaining(['order-service', 'inventory-service', 'payment-service'])
  );

  // No errors in the happy path
  expect(trace.hasErrors).toBe(false);

  // Order span has the order ID
  const orderSpan = trace.spans.find(s => s.operation === 'POST /orders');
  expect(orderSpan.tags['order.id']).toBe(orderId);

  // Performance: root span within SLO
  expect(orderSpan.durationMs).toBeLessThan(1000);
});

Testing Failure Scenarios End-to-End

test('payment failure — UI shows error, trace shows payment span error', async ({ page }) => {
  const startMs = Date.now();

  await page.goto('http://localhost:3000');
  await page.click('[data-testid="product-A"]');
  await page.click('[data-testid="add-to-cart"]');
  await page.click('[data-testid="checkout-btn"]');

  // Use a declined test card
  await page.fill('[data-testid="card-number"]', '4000000000000002');
  await page.fill('[data-testid="card-expiry"]', '12/26');
  await page.fill('[data-testid="card-cvv"]', '123');
  await page.click('[data-testid="place-order-btn"]');

  // UI should show error message
  await expect(page.locator('[data-testid="payment-error"]')).toBeVisible();
  await expect(page.locator('[data-testid="payment-error"]')).toContainText('card declined');

  // Trace should show error on payment span
  const trace = analyzeTrace(await findTrace('order-service', 'POST /orders', startMs));
  const paymentSpan = trace.spans.find(s => s.service === 'payment-service');

  expect(paymentSpan).toBeDefined();
  expect(paymentSpan.hasError).toBe(true);
  expect(paymentSpan.tags['error.type']).toBe('card_declined');
});

Extracting the Trace ID from the Response

For more precise trace lookup, extract the trace ID from the response headers:

// Instrument your app to return trace ID in response header
// app.js
app.use((req, res, next) => {
  const span = trace.getActiveSpan();
  if (span) {
    res.setHeader('X-Trace-Id', span.spanContext().traceId);
  }
  next();
});
// In your test, capture the trace ID via network interception
test('lookup trace by ID from response header', async ({ page }) => {
  let traceId;

  await page.route('**/orders', async (route) => {
    const response = await route.fetch();
    traceId = response.headers()['x-trace-id'];
    await route.fulfill({ response });
  });

  await page.goto('http://localhost:3000');
  // ... fill form and submit ...
  await page.click('[data-testid="place-order-btn"]');

  // Now look up by exact trace ID — no timing uncertainty
  const res = await fetch(`http://localhost:16686/api/traces/${traceId}`);
  const json = await res.json();
  const trace = analyzeTrace(json.data[0]);

  expect(trace.hasErrors).toBe(false);
});

Playwright Fixtures for Trace Assertions

// tests/fixtures.js
const { test: base } = require('@playwright/test');
const { findTrace, analyzeTrace } = require('./helpers/jaeger');

const test = base.extend({
  // Fixture that captures test start time and provides trace lookup
  withTracing: async ({}, use) => {
    const startMs = Date.now();

    const getTrace = async (service, operation) => {
      const raw = await findTrace(service, operation, startMs);
      return analyzeTrace(raw);
    };

    await use({ getTrace, startMs });
  },
});

module.exports = { test };
// tests/order.spec.js
const { test } = require('./fixtures');
const { expect } = require('@playwright/test');

test('order placement with trace fixture', async ({ page, withTracing }) => {
  const { getTrace } = withTracing;

  // ... UI actions ...
  await page.click('[data-testid="place-order-btn"]');
  await expect(page.locator('[data-testid="order-confirmation"]')).toBeVisible();

  const trace = await getTrace('order-service', 'POST /orders');
  expect(trace.services).toContain('payment-service');
  expect(trace.hasErrors).toBe(false);
});

Running in CI

# .github/workflows/e2e.yml
jobs:
  e2e:
    runs-on: ubuntu-latest
    services:
      jaeger:
        image: jaegertracing/all-in-one:latest
        env:
          COLLECTOR_OTLP_ENABLED: "true"
        ports:
          - 16686:16686
          - 4318:4318

    steps:
      - uses: actions/checkout@v4
      - run: npm ci
      - run: npx playwright install --with-deps chromium
      - name: Start app
        run: |
          OTEL_EXPORTER_OTLP_ENDPOINT=http://localhost:4318/v1/traces \
          OTEL_SERVICE_NAME=order-service \
          node server.js &
          npx wait-on http://localhost:3000
      - run: npx playwright test

Summary

Combining Playwright with OpenTelemetry gives you:

  • UI correctness — what the user sees is right
  • Backend correctness — every service involved, no errors, within latency SLOs
  • Failure precision — when a test fails, you know exactly which service and span caused it

The implementation is a helper function + a few extra expect calls. The payoff is that a passing Playwright suite now means both "the UI works" and "the backend distributed execution is correct."

This is the closest you can get to production confidence in a CI environment.
