Meta Quest Testing: Automation with Appium and ADB

adb devices
# Should output something like:
# 1WMHHA123456789    device

# If you see "unauthorized", the prompt inside the headset was not accepted
adb kill-server && adb start-server
adb devices  # try again after accepting the in-headset prompt

# Connect once via USB to set up TCP/IP mode
adb tcpip 5555

# Find Quest's IP (in headset: Settings > Wi-Fi > (network name) > Advanced)
QUEST_IP=192.168.1.42

# Connect wirelessly
adb connect $QUEST_IP:5555
adb devices  # should show the wireless connection

#!/usr/bin/env bash
# scripts/detect-quest-mode.sh

DEVICE=${1:-$(adb devices | grep device | grep -v List | head -1 | cut -f1)}
LINK_SERVICE=$(adb -s "$DEVICE" shell getprop ro.build.product 2>/dev/null)
LINK_ACTIVE=$(adb -s "$DEVICE" shell pm list packages | grep com.oculus.link 2>/dev/null)

echo "Device: $DEVICE"
echo "Build: $LINK_SERVICE"
if [ -n "$LINK_ACTIVE" ] && adb -s "$DEVICE" shell pidof com.oculus.systemdriver > /dev/null 2>&1; then
    echo "Mode: Quest Link (PCVR)"
else
    echo "Mode: Standalone (Android)"
fi

npm install -g appium
appium driver install uiautomator2
appium &  # start server

# tests/test_quest_launcher.py
import pytest
from appium import webdriver
from appium.options import AppiumOptions
from appium.webdriver.common.appiumby import AppiumBy

QUEST_DEVICE = "1WMHHA123456789"  # from adb devices

@pytest.fixture
def driver():
    options = AppiumOptions()
    options.platform_name = "Android"
    options.load_capability("appium:deviceName", "Meta Quest 3")
    options.load_capability("appium:udid", QUEST_DEVICE)
    options.load_capability("appium:automationName", "UiAutomator2")
    options.load_capability("appium:appPackage", "com.oculus.tv")
    options.load_capability("appium:appActivity", ".MainActivity")
    options.load_capability("appium:noReset", True)
    options.load_capability("appium:newCommandTimeout", 120)

    drv = webdriver.Remote("http://localhost:4723", options=options)
    yield drv
    drv.quit()


def test_app_launches_without_crash(driver):
    """Verify the app launches and shows the main content grid."""
    # Wait for main content to appear
    content_grid = driver.find_element(
        AppiumBy.ID, "com.oculus.tv:id/content_grid"
    )
    assert content_grid.is_displayed(), "Content grid should be visible on launch"


def test_search_returns_results(driver):
    """Verify search functionality returns results."""
    search_button = driver.find_element(
        AppiumBy.ACCESSIBILITY_ID, "Search"
    )
    search_button.click()

    search_input = driver.find_element(
        AppiumBy.ID, "com.oculus.tv:id/search_input"
    )
    search_input.send_keys("Netflix")

    results = driver.find_elements(
        AppiumBy.ID, "com.oculus.tv:id/search_result_item"
    )
    assert len(results) > 0, "Search should return at least one result"

#!/usr/bin/env bash
# scripts/launch-and-monitor.sh

PACKAGE="com.yourcompany.vrapp"
ACTIVITY="com.yourcompany.vrapp.MainActivity"
DEVICE=${1:-$(adb devices | grep -m1 "device$" | cut -f1)}
TIMEOUT=30

echo "Launching $PACKAGE on $DEVICE..."

# Clear previous logs
adb -s "$DEVICE" logcat -c

# Launch the app
adb -s "$DEVICE" shell am start -n "$PACKAGE/$ACTIVITY"

# Monitor for crash signals for TIMEOUT seconds
END=$((SECONDS + TIMEOUT))
CRASHED=false

while [ $SECONDS -lt $END ]; do
    if adb -s "$DEVICE" logcat -d | grep -q "FATAL EXCEPTION\|AndroidRuntime: FATAL\|Process: $PACKAGE.*died"; then
        CRASHED=true
        break
    fi
    sleep 1
done

if $CRASHED; then
    echo "FAIL: App crashed during launch"
    adb -s "$DEVICE" logcat -d | grep -A 20 "FATAL EXCEPTION" | tail -25
    exit 1
else
    echo "PASS: App ran for $TIMEOUT seconds without crash"
    PID=$(adb -s "$DEVICE" shell pidof "$PACKAGE")
    echo "App PID: $PID"
fi

#!/usr/bin/env bash
# scripts/run-perf-test.sh

PACKAGE="com.yourcompany.vrapp"
DEVICE=${1:-$(adb devices | grep -m1 "device$" | cut -f1)}
OUTPUT_DIR="./perf-results"
DURATION=60  # seconds

mkdir -p "$OUTPUT_DIR"

# Start OVR Metrics capture
adb -s "$DEVICE" shell am broadcast \
    -a com.oculus.ovrmetricstool.CAPTURE_START \
    -p com.oculus.ovrmetricstool

# Launch the app
adb -s "$DEVICE" shell am start \
    -n "$PACKAGE/com.yourcompany.vrapp.MainActivity"

echo "Capturing performance for ${DURATION}s..."
sleep "$DURATION"

# Stop capture and pull results
adb -s "$DEVICE" shell am broadcast \
    -a com.oculus.ovrmetricstool.CAPTURE_STOP \
    -p com.oculus.ovrmetricstool

sleep 2

# Pull the CSV from the device
adb -s "$DEVICE" pull \
    /sdcard/OVRMetrics/ \
    "$OUTPUT_DIR/"

echo "Performance data saved to $OUTPUT_DIR/"

# scripts/analyze_perf.py
import csv
import sys
from pathlib import Path

def analyze_frame_times(csv_path: str, target_fps: int = 72) -> bool:
    target_ms = 1000.0 / target_fps
    frame_times = []

    with open(csv_path) as f:
        reader = csv.DictReader(f)
        for row in reader:
            if "GPU Time (ms)" in row:
                try:
                    frame_times.append(float(row["GPU Time (ms)"]))
                except ValueError:
                    continue

    if not frame_times:
        print("ERROR: No frame time data found")
        return False

    avg = sum(frame_times) / len(frame_times)
    p95 = sorted(frame_times)[int(len(frame_times) * 0.95)]
    p99 = sorted(frame_times)[int(len(frame_times) * 0.99)]
    worst = max(frame_times)
    over_budget = sum(1 for t in frame_times if t > target_ms)
    over_pct = (over_budget / len(frame_times)) * 100

    print(f"Frame count: {len(frame_times)}")
    print(f"Target: {target_ms:.2f}ms ({target_fps}Hz)")
    print(f"Average GPU time: {avg:.2f}ms")
    print(f"P95: {p95:.2f}ms")
    print(f"P99: {p99:.2f}ms")
    print(f"Worst: {worst:.2f}ms")
    print(f"Over budget: {over_pct:.1f}% of frames")

    passed = over_pct < 2.0  # fail if more than 2% of frames miss budget
    print(f"Result: {'PASS' if passed else 'FAIL'}")
    return passed


if __name__ == "__main__":
    csv_file = sys.argv[1] if len(sys.argv) > 1 else "perf-results/metrics.csv"
    ok = analyze_frame_times(csv_file)
    sys.exit(0 if ok else 1)

# Download from https://developer.oculus.com/downloads/package/oculus-platform-tool/
# Place in your PATH

# Upload a build to the ALPHA channel
ovr-platform-tool upload-quest-build \
    --app-id "$META_APP_ID" \
    --app-secret "$META_APP_SECRET" \
    --apk "build/MyApp.apk" \
    --channel ALPHA \
    --notes "CI build $GITHUB_SHA"

# Install directly via ADB for device testing (faster than store channel)
adb install -r build/MyApp.apk

#!/usr/bin/env bash
# scripts/run-unity-tests-on-device.sh

PACKAGE="com.yourcompany.vrapp.tests"
DEVICE=${1:-$(adb devices | grep -m1 "device$" | cut -f1)}
RESULTS_DIR="./test-results"
RESULTS_XML="$RESULTS_DIR/unity-device-tests.xml"

mkdir -p "$RESULTS_DIR"

echo "Installing test APK on $DEVICE..."
adb -s "$DEVICE" install -r build/MyApp-Tests.apk

echo "Running Unity Play Mode tests..."
adb -s "$DEVICE" shell am instrument \
    -w \
    -e class "MyVRApp.Tests.PlayMode" \
    "$PACKAGE/com.unity3d.player.UnityPlayerActivity" \
    2>&1 | tee /tmp/unity-test-output.txt

# Parse Unity's output for results
PASSED=$(grep -c "^OK" /tmp/unity-test-output.txt || true)
FAILED=$(grep -c "^FAIL" /tmp/unity-test-output.txt || true)

echo "Passed: $PASSED"
echo "Failed: $FAILED"

# Pull XML results if you configured Unity to write them
adb -s "$DEVICE" pull \
    /sdcard/Android/data/$PACKAGE/files/test-results.xml \
    "$RESULTS_XML" 2>/dev/null || true

if [ "$FAILED" -gt 0 ]; then
    echo "FAIL: $FAILED tests failed on device"
    exit 1
fi
echo "PASS: All tests passed on Quest"

# scripts/thermal_test.py
import subprocess
import time
import json

DEVICE = subprocess.check_output(
    ["adb", "devices"], text=True
).strip().split("\n")[1].split("\t")[0]


def get_thermal_zone(zone_name: str) -> float:
    """Read thermal zone temperature in Celsius."""
    result = subprocess.run(
        ["adb", "-s", DEVICE, "shell",
         f"cat /sys/class/thermal/thermal_zone*/type /sys/class/thermal/thermal_zone*/temp"],
        capture_output=True, text=True,
    )
    lines = result.stdout.strip().split("\n")
    types = lines[:len(lines)//2]
    temps = lines[len(lines)//2:]

    for t, v in zip(types, temps):
        if zone_name.lower() in t.lower():
            try:
                return float(v) / 1000.0
            except ValueError:
                pass
    return -1.0


def test_thermal_stability(duration_seconds: int = 300):
    """Run app for N seconds and verify thermal throttling stays manageable."""
    package = "com.yourcompany.vrapp"
    subprocess.run(["adb", "-s", DEVICE, "shell", "am", "start",
                    "-n", f"{package}/.MainActivity"])

    readings = []
    throttle_events = 0

    print(f"Monitoring thermals for {duration_seconds}s...")
    for i in range(duration_seconds // 5):
        time.sleep(5)
        gpu_temp = get_thermal_zone("gpu")
        cpu_temp = get_thermal_zone("cpu")
        readings.append({"time": i * 5, "gpu_c": gpu_temp, "cpu_c": cpu_temp})

        # Check for throttling via OVR log
        log = subprocess.check_output(
            ["adb", "-s", DEVICE, "logcat", "-d", "-t", "10",
             "-s", "OVRPlugin:W"],
            text=True,
        )
        if "THROTTLING" in log or "SpaceWarp" in log:
            throttle_events += 1

        print(f"  t={i*5:3d}s  GPU={gpu_temp:.1f}°C  CPU={cpu_temp:.1f}°C"
              f"  throttles={throttle_events}")

    max_gpu = max(r["gpu_c"] for r in readings)
    print(f"\nMax GPU temp: {max_gpu:.1f}°C")
    print(f"Throttle events: {throttle_events}")

    # Quest 3 thermal limit is ~80°C for GPU
    assert max_gpu < 80.0, f"GPU reached {max_gpu:.1f}°C — thermal limit exceeded"
    assert throttle_events < 5, f"Too many throttle events: {throttle_events}"
    print("PASS: Thermal test completed within bounds")


if __name__ == "__main__":
    test_thermal_stability()

npm install -g sidequest-cli

# Install APK
sidequest install build/MyApp.apk --device "$QUEST_DEVICE"

# List installed packages
sidequest packages --device "$QUEST_DEVICE"

# Uninstall
sidequest uninstall com.yourcompany.vrapp --device "$QUEST_DEVICE"

adb install -r build/MyApp.apk && \
adb shell pm list packages | grep com.yourcompany.vrapp && \
echo "Install verified"

name: Quest Tests
on: [push, pull_request]

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - name: Build APK
        uses: game-ci/unity-builder@v4
        with:
          targetPlatform: Android
          buildName: MyVRApp

  device-tests:
    needs: build
    runs-on: self-hosted  # your lab runner with Quest connected
    steps:
      - uses: actions/checkout@v4
      - name: Download APK
        uses: actions/download-artifact@v4
        with:
          name: Build-Android

      - name: Install on Quest
        run: adb install -r MyVRApp.apk

      - name: Run smoke tests
        run: bash scripts/launch-and-monitor.sh

      - name: Run Unity device tests
        run: bash scripts/run-unity-tests-on-device.sh

      - name: Collect performance metrics
        run: |
          bash scripts/run-perf-test.sh
          python scripts/analyze_perf.py perf-results/metrics.csv

      - name: Upload results
        uses: actions/upload-artifact@v4
        if: always()
        with:
          name: quest-test-results
          path: |
            test-results/
            perf-results/
