Test Reporting in CI: Aggregating JUnit XML Across Jest, pytest, Go test, and Rust

HelpMeTest

17 May 2026 — 7 min read

JUnit XML is the lingua franca of test reporting. Originally a JUnit (Java) format, it's been adopted by every major test framework across every language. GitHub Actions, GitLab CI, Jenkins, CircleCI, and most other CI platforms can parse and display JUnit XML natively. Understanding how to generate and aggregate it across a polyglot codebase is a fundamental CI skill.

The JUnit XML Format

JUnit XML is simple:

<?xml version="1.0" encoding="UTF-8"?>
<testsuites>
  <testsuite name="LoginTests" tests="3" failures="1" errors="0" skipped="0" time="1.234">
    <testcase name="successful login" classname="auth.LoginTests" time="0.456">
      <!-- No child element = passed -->
    </testcase>
    <testcase name="login fails with wrong password" classname="auth.LoginTests" time="0.234">
      <!-- Failure with message and stack trace -->
      <failure message="AssertionError: Expected 'dashboard' but got 'login'">
        AssertionError: Expected 'dashboard' but got 'login'
          at login_fails_with_wrong_password (tests/login.test.js:23:5)
      </failure>
    </testcase>
    <testcase name="login page loads" classname="auth.LoginTests" time="0.544">
      <skipped message="Skipped in staging environment"/>
    </testcase>
  </testsuite>
</testsuites>

Key attributes:

tests: total test count
failures: assertion failures
errors: test errors (exceptions, crashes)
skipped: skipped tests
time: duration in seconds

Generating JUnit XML by Framework

Jest (JavaScript)

npm install --save-dev jest-junit

// jest.config.js
module.exports = {
  reporters: [
    'default',
    ['jest-junit', {
      outputDirectory: 'reports',
      outputName: 'jest-junit.xml',
      classNameTemplate: '{classname}',
      titleTemplate: '{title}',
      ancestorSeparator: ' > ',
      usePathForSuiteName: true,
    }]
  ]
};

# Or via CLI
JEST_JUNIT_OUTPUT_DIR=reports npx jest --reporters=jest-junit

<span class="hljs-comment"># Verify output
<span class="hljs-built_in">cat reports/jest-junit.xml

pytest (Python)

pytest has built-in JUnit XML support:

# Generate JUnit XML
pytest tests/ --junit-xml=reports/pytest-junit.xml

<span class="hljs-comment"># With verbose output
pytest tests/ --junit-xml=reports/pytest-junit.xml -v

<span class="hljs-comment"># With properties (extra metadata)
pytest tests/ \
  --junit-xml=reports/pytest-junit.xml \
  --junit-prefix=myapp

# pytest.ini
[pytest]
junit_logging = all
junit_log_passing_tests = true
junit_duration_report = total

Custom properties per test:

# conftest.py
def pytest_runtest_makereport(item, call):
    if call.when == "call":
        item._report_sections = getattr(item, '_report_sections', [])

# test_example.py
def test_api_response(record_property):
    response = make_api_call()
    record_property("status_code", response.status_code)
    record_property("response_time_ms", response.elapsed.microseconds // 1000)
    assert response.status_code == 200

Go

Go's testing package generates JUnit XML via go-junit-report:

# Install
go install github.com/jstemmer/go-junit-report/v2@latest

<span class="hljs-comment"># Run tests and convert output
go <span class="hljs-built_in">test ./... -v -count=1 2>&1 <span class="hljs-pipe">| go-junit-report -set-exit-code > reports/go-junit.xml

<span class="hljs-comment"># With timing
go <span class="hljs-built_in">test ./... -v -count=1 -<span class="hljs-built_in">timeout 300s 2>&1 <span class="hljs-pipe">| go-junit-report > reports/go-junit.xml

For gotestsum (recommended for clean output):

go install gotest.tools/gotestsum@latest

# Generate JUnit XML directly
gotestsum --junitfile reports/go-junit.xml -- ./...

<span class="hljs-comment"># With package-level output
gotestsum --junitfile reports/go-junit.xml --junitfile-testcase-classname short ./...

Rust

# Install cargo-junit
cargo install cargo-junit

<span class="hljs-comment"># Or use cargo-nextest (recommended)
cargo install cargo-nextest

<span class="hljs-comment"># cargo-nextest generates JUnit XML natively
cargo nextest run --profile ci

<span class="hljs-comment"># Default output location
<span class="hljs-built_in">ls target/nextest/ci/junit.xml

Custom nextest config:

# .config/nextest.toml
[profile.ci]
failure-output = "immediate-final"
success-output = "never"
status-level = "fail"

[[profile.ci.junit]]
path = "reports/nextest-junit.xml"

Ruby (RSpec)

# Gemfile
gem 'rspec_junit_formatter'

# .rspec
--format RspecJunitFormatter
--out reports/rspec-junit.xml
--format progress

<span class="hljs-comment"># Or CLI
rspec --format RspecJunitFormatter --out reports/rspec-junit.xml

.NET (xUnit, NUnit, MSTest)

# xUnit with dotnet test
dotnet <span class="hljs-built_in">test --logger <span class="hljs-string">"junit;LogFilePath=reports/xunit-junit.xml"

<span class="hljs-comment"># NUnit
dotnet <span class="hljs-built_in">test --logger <span class="hljs-string">"nunit;LogFileName=reports/nunit-result.xml"

<span class="hljs-comment"># MSTest
dotnet <span class="hljs-built_in">test --logger <span class="hljs-string">"trx;LogFileName=reports/mstest.trx"
<span class="hljs-comment"># Convert TRX to JUnit XML if needed

PHP (PHPUnit)

<!-- phpunit.xml -->
<phpunit>
    <logging>
        <junit outputFile="reports/phpunit-junit.xml"/>
    </logging>
</phpunit>

phpunit --log-junit reports/phpunit-junit.xml

Aggregating Multiple Reports

When multiple test suites generate separate XML files, merge them before presenting to CI:

Simple Merge (Cat XML)

JUnit XML supports multiple <testsuite> elements under <testsuites>. You can concatenate them:

#!/usr/bin/env python3
"""Merge multiple JUnit XML files into one"""

import xml.etree.ElementTree as ET
import glob
import sys

output_file = sys.argv[1]
input_pattern = sys.argv[2]

merged = ET.Element('testsuites')

totals = {'tests': 0, 'failures': 0, 'errors': 0, 'skipped': 0, 'time': 0.0}

for xml_file in glob.glob(input_pattern):
    tree = ET.parse(xml_file)
    root = tree.getroot()

    # Handle both <testsuites> and <testsuite> roots
    if root.tag == 'testsuites':
        suites = root.findall('testsuite')
    else:
        suites = [root]

    for suite in suites:
        merged.append(suite)
        totals['tests'] += int(suite.get('tests', 0))
        totals['failures'] += int(suite.get('failures', 0))
        totals['errors'] += int(suite.get('errors', 0))
        totals['skipped'] += int(suite.get('skipped', 0))
        totals['time'] += float(suite.get('time', 0))

# Set totals on root element
for key, value in totals.items():
    merged.set(key, str(value))

ET.ElementTree(merged).write(output_file, xml_declaration=True, encoding='utf-8')
print(f"Merged {len(list(merged))} test suites → {output_file}")
print(f"Total: {totals['tests']} tests, {totals['failures']} failures, {totals['errors']} errors")

python3 merge-junit.py reports/merged.xml "reports/*.xml"

junit-xml-merge (npm)

npm install -g junit-xml-merge

# Merge all XML files in reports/
junit-xml-merge --output reports/merged.xml reports/*.xml

GitHub Actions Integration

GitHub Actions natively parses JUnit XML from test steps and shows results inline:

name: Test

on: [push, pull_request]

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      # JavaScript
      - name: Run Jest
        run: npm test
        env:
          JEST_JUNIT_OUTPUT_DIR: reports

      # Python
      - name: Run pytest
        run: pytest tests/ --junit-xml=reports/pytest-junit.xml

      # Go
      - name: Run Go tests
        run: |
          go install gotest.tools/gotestsum@latest
          gotestsum --junitfile reports/go-junit.xml -- ./...

      # Publish test results
      - name: Publish Test Results
        uses: EnricoMi/publish-unit-test-result-action@v2
        if: always()
        with:
          files: reports/**/*.xml
          check_name: Test Results
          comment_on_pr: true

      # Also upload as artifact
      - name: Upload test reports
        uses: actions/upload-artifact@v4
        if: always()
        with:
          name: test-reports
          path: reports/

The publish-unit-test-result-action adds a check to the PR showing test counts, failure details, and trend data.

Alternative: dorny/test-reporter

- name: Test Reporter
  uses: dorny/test-reporter@v1
  if: always()
  with:
    name: Tests
    path: reports/**/*.xml
    reporter: java-junit
    fail-on-error: true

GitLab CI Integration

GitLab CI has native JUnit XML parsing:

test:
  script:
    - pytest tests/ --junit-xml=reports/junit.xml
    - npm test -- --reporters=jest-junit
    - gotestsum --junitfile reports/go-junit.xml -- ./...
  artifacts:
    when: always
    reports:
      junit:
        - reports/junit.xml
        - reports/jest-junit.xml
        - reports/go-junit.xml
    paths:
      - reports/
    expire_in: 30 days

GitLab displays test results in the merge request widget with failure details and history.

Jenkins Integration

// Jenkinsfile
pipeline {
    agent any

    stages {
        stage('Test') {
            steps {
                sh 'pytest tests/ --junit-xml=reports/pytest-junit.xml'
                sh 'npm test'
                sh 'gotestsum --junitfile reports/go-junit.xml -- ./...'
            }
            post {
                always {
                    junit 'reports/**/*.xml'
                    archiveArtifacts artifacts: 'reports/**', allowEmptyArchive: true
                }
            }
        }
    }
}

Polyglot CI Pipeline Example

Real services often have multiple languages. This example handles a Node.js frontend, Python backend, and Go service:

name: Polyglot Test Suite

on: [push, pull_request]

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup Node.js
        uses: actions/setup-node@v4
        with:
          node-version: '20'

      - name: Setup Python
        uses: actions/setup-python@v5
        with:
          python-version: '3.12'

      - name: Setup Go
        uses: actions/setup-go@v5
        with:
          go-version: '1.22'

      # Install all dependencies
      - run: npm ci
      - run: pip install -r requirements.txt pytest pytest-junit
      - run: go install gotest.tools/gotestsum@latest

      # Run all test suites
      - name: Run frontend tests (Jest)
        run: npm test
        env:
          JEST_JUNIT_OUTPUT_DIR: test-results
          JEST_JUNIT_OUTPUT_NAME: frontend.xml

      - name: Run backend tests (pytest)
        run: pytest backend/tests/ --junit-xml=test-results/backend.xml

      - name: Run service tests (Go)
        run: gotestsum --junitfile test-results/service.xml -- ./service/...

      # Publish combined results
      - name: Publish all test results
        uses: EnricoMi/publish-unit-test-result-action@v2
        if: always()
        with:
          files: test-results/**/*.xml
          check_name: All Tests
          comment_mode: create new
          compare_to_earlier_commit: true

Analyzing JUnit XML Programmatically

#!/usr/bin/env python3
"""Parse and summarize JUnit XML results"""

import xml.etree.ElementTree as ET
import sys
from pathlib import Path
from collections import defaultdict

def parse_junit(file_path):
    tree = ET.parse(file_path)
    root = tree.getroot()

    suites = root.findall('.//testsuite')
    results = {
        'total': 0, 'passed': 0, 'failed': 0,
        'errors': 0, 'skipped': 0, 'time': 0.0,
        'failures': []
    }

    for suite in suites:
        results['total'] += int(suite.get('tests', 0))
        results['failed'] += int(suite.get('failures', 0))
        results['errors'] += int(suite.get('errors', 0))
        results['skipped'] += int(suite.get('skipped', 0))
        results['time'] += float(suite.get('time', 0))

        for case in suite.findall('testcase'):
            failure = case.find('failure')
            error = case.find('error')
            if failure is not None or error is not None:
                results['failures'].append({
                    'name': case.get('name'),
                    'classname': case.get('classname'),
                    'message': (failure or error).get('message', ''),
                    'duration': float(case.get('time', 0))
                })

    results['passed'] = results['total'] - results['failed'] - results['errors'] - results['skipped']
    return results

if __name__ == '__main__':
    all_results = defaultdict(int)

    for xml_file in Path('test-results').glob('*.xml'):
        results = parse_junit(xml_file)
        suite_name = xml_file.stem
        print(f"\n{suite_name}:")
        print(f"  Tests: {results['total']} | Pass: {results['passed']} | "
              f"Fail: {results['failed']} | Skip: {results['skipped']} | "
              f"Time: {results['time']:.1f}s")

        for key in ('total', 'passed', 'failed', 'skipped'):
            all_results[key] += results[key]

        if results['failures']:
            print("  Failures:")
            for f in results['failures'][:3]:  # Show first 3
                print(f"    ✗ {f['classname']}.{f['name']}")
                print(f"      {f['message'][:100]}")

    print(f"\nTotal: {all_results['total']} tests | "
          f"{all_results['passed']} passed | "
          f"{all_results['failed']} failed | "
          f"{all_results['skipped']} skipped")

    sys.exit(1 if all_results['failed'] > 0 else 0)

JUnit XML's ubiquity makes it the best choice for CI test reporting in polyglot environments. Generate it from every test framework, aggregate it in CI, and let your CI platform handle the display. The overhead is minimal and the visibility gains are significant.
