Testing

GraphQL Integration Testing with Supertest and Node.js

HelpMeTest

15 May 2026 — 5 min read

Apollo Server's executeOperation is excellent for most GraphQL testing. But sometimes you need to test the full HTTP stack — middleware, authentication headers, CORS, rate limiting, and HTTP error codes. Supertest lets you do that: it sends real HTTP requests against your Express/Fastify application without starting a network listener.

This guide covers GraphQL integration testing with Supertest, including auth flows, pagination, complex error handling, and CI setup.

When to Use Supertest vs executeOperation

Use executeOperation when:

Testing resolver logic and data transformation
Testing authorization in context
Speed matters (no HTTP overhead)
You control the context injection directly

Use Supertest when:

Testing authentication middleware (JWT parsing, cookie-based auth)
Testing CORS or rate limiting
Testing persisted query endpoints
Testing multipart uploads (file uploads via GraphQL)
Verifying HTTP status codes (some APIs return non-200 on errors)
Testing introspection disable behavior

Setup

npm install supertest
npm install --save-dev @types/supertest

Your Apollo Server needs to be attached to an Express app:

// src/app.ts
import express from 'express';
import { ApolloServer } from '@apollo/server';
import { expressMiddleware } from '@apollo/server/express4';
import cors from 'cors';
import { typeDefs, resolvers } from './schema';
import { createContext } from './context';

export async function createApp() {
  const app = express();

  const server = new ApolloServer({ typeDefs, resolvers });
  await server.start();

  app.use(cors());
  app.use(express.json());

  app.use(
    '/graphql',
    expressMiddleware(server, {
      context: createContext,
    })
  );

  return { app, server };
}

Basic Supertest GraphQL Helper

// tests/helpers/request.ts
import supertest from 'supertest';
import { Express } from 'express';

interface GraphQLRequest {
  query: string;
  variables?: Record<string, unknown>;
  operationName?: string;
}

export function graphql(app: Express) {
  return {
    async execute(
      request: GraphQLRequest,
      options: {
        authToken?: string;
        headers?: Record<string, string>;
        expectedStatus?: number;
      } = {}
    ) {
      const { authToken, headers = {}, expectedStatus = 200 } = options;

      const req = supertest(app)
        .post('/graphql')
        .set('Content-Type', 'application/json')
        .set('Accept', 'application/json');

      if (authToken) {
        req.set('Authorization', `Bearer ${authToken}`);
      }

      Object.entries(headers).forEach(([key, value]) => req.set(key, value));

      const response = await req.send(request);

      expect(response.status).toBe(expectedStatus);
      return response.body;
    },
  };
}

Authentication Testing

One of the biggest advantages of Supertest over executeOperation is testing real JWT/session middleware:

// tests/integration/auth.test.ts
import { createApp } from '../../src/app';
import { graphql } from '../helpers/request';
import { generateToken } from '../../src/auth';
import { testDb } from '../helpers/testDb';

let app: Express;
let gql: ReturnType<typeof graphql>;

beforeAll(async () => {
  const setup = await createApp();
  app = setup.app;
  gql = graphql(app);
  await testDb.migrate();
});

afterAll(() => testDb.close());
beforeEach(() => testDb.seed());
afterEach(() => testDb.cleanup());

describe('Authentication', () => {
  it('returns user data with valid JWT', async () => {
    const token = generateToken({ userId: '1', role: 'user' });

    const body = await gql.execute(
      { query: `query { me { id email } }` },
      { authToken: token }
    );

    expect(body.errors).toBeUndefined();
    expect(body.data.me.id).toBe('1');
  });

  it('returns UNAUTHENTICATED without token', async () => {
    const body = await gql.execute(
      { query: `query { me { id } }` }
      // no authToken
    );

    expect(body.errors[0].extensions.code).toBe('UNAUTHENTICATED');
    expect(body.data.me).toBeNull();
  });

  it('returns UNAUTHENTICATED with expired token', async () => {
    const expiredToken = generateToken({ userId: '1' }, { expiresIn: '-1s' });

    const body = await gql.execute(
      { query: `query { me { id } }` },
      { authToken: expiredToken }
    );

    expect(body.errors[0].extensions.code).toBe('UNAUTHENTICATED');
  });

  it('returns UNAUTHENTICATED with malformed token', async () => {
    const body = await gql.execute(
      { query: `query { me { id } }` },
      { authToken: 'not-a-valid-jwt' }
    );

    expect(body.errors[0].extensions.code).toBe('UNAUTHENTICATED');
  });
});

Pagination Testing

Pagination bugs are common. Test cursor-based pagination thoroughly:

describe('Pagination', () => {
  beforeEach(async () => {
    // Create 25 products in a known order
    await testDb.products.bulkCreate(
      Array.from({ length: 25 }, (_, i) => ({
        name: `Product ${i + 1}`,
        price: (i + 1) * 10,
      }))
    );
  });

  const PRODUCTS_QUERY = `
    query Products($first: Int, $after: String, $last: Int, $before: String) {
      products(first: $first, after: $after, last: $last, before: $before) {
        edges {
          cursor
          node {
            id
            name
          }
        }
        pageInfo {
          hasNextPage
          hasPreviousPage
          startCursor
          endCursor
        }
        totalCount
      }
    }
  `;

  const token = generateToken({ userId: '1', role: 'user' });

  it('returns first page with hasNextPage=true', async () => {
    const body = await gql.execute(
      { query: PRODUCTS_QUERY, variables: { first: 10 } },
      { authToken: token }
    );

    const { edges, pageInfo, totalCount } = body.data.products;
    expect(edges).toHaveLength(10);
    expect(pageInfo.hasNextPage).toBe(true);
    expect(pageInfo.hasPreviousPage).toBe(false);
    expect(totalCount).toBe(25);
  });

  it('returns second page correctly', async () => {
    // Get first page to get cursor
    const first = await gql.execute(
      { query: PRODUCTS_QUERY, variables: { first: 10 } },
      { authToken: token }
    );
    const endCursor = first.data.products.pageInfo.endCursor;

    // Get second page
    const second = await gql.execute(
      { query: PRODUCTS_QUERY, variables: { first: 10, after: endCursor } },
      { authToken: token }
    );

    expect(second.data.products.edges).toHaveLength(10);
    // Second page should not contain any items from first page
    const firstIds = first.data.products.edges.map((e: any) => e.node.id);
    const secondIds = second.data.products.edges.map((e: any) => e.node.id);
    const overlap = firstIds.filter((id: string) => secondIds.includes(id));
    expect(overlap).toHaveLength(0);
  });

  it('returns last page with hasNextPage=false', async () => {
    const body = await gql.execute(
      { query: PRODUCTS_QUERY, variables: { first: 30 } }, // more than total
      { authToken: token }
    );

    expect(body.data.products.edges).toHaveLength(25);
    expect(body.data.products.pageInfo.hasNextPage).toBe(false);
  });

  it('returns empty for out-of-range cursor', async () => {
    const body = await gql.execute(
      {
        query: PRODUCTS_QUERY,
        variables: { first: 10, after: 'invalid-cursor-xyz' },
      },
      { authToken: token }
    );

    // Should return empty or error — depends on implementation
    // Test whatever your API is supposed to do
    expect(body.errors || body.data.products.edges).toBeDefined();
  });
});

Error Handling Patterns

GraphQL errors behave differently from REST. Test each error path explicitly:

describe('Error handling', () => {
  const token = generateToken({ userId: '1', role: 'user' });

  it('returns 200 with errors array on resolver error', async () => {
    // Note: GraphQL returns 200 even for errors
    const body = await gql.execute(
      { query: `query { user(id: "nonexistent") { id name } }` },
      { authToken: token, expectedStatus: 200 }
    );

    expect(body.data.user).toBeNull();
    expect(body.errors[0].extensions.code).toBe('NOT_FOUND');
    expect(body.errors[0].path).toEqual(['user']);
  });

  it('returns 400 for invalid GraphQL syntax', async () => {
    const response = await supertest(app)
      .post('/graphql')
      .set('Authorization', `Bearer ${token}`)
      .send({ query: 'this is not valid graphql {{{}' });

    expect(response.status).toBe(400);
  });

  it('returns partial data with errors for field-level errors', async () => {
    // A query where one field succeeds and another fails
    const body = await gql.execute(
      {
        query: `query {
          user(id: "1") { id name }
          user2: user(id: "nonexistent") { id name }
        }`,
      },
      { authToken: token }
    );

    // user should be present
    expect(body.data.user).not.toBeNull();
    // user2 should be null (error)
    expect(body.data.user2).toBeNull();
    // errors array should have one error for user2
    expect(body.errors).toHaveLength(1);
    expect(body.errors[0].path).toEqual(['user2']);
  });

  it('masks internal errors in production', async () => {
    // Force an unexpected error
    jest.spyOn(testDb.users, 'findById').mockRejectedValueOnce(
      new Error('INTERNAL: db connection pool exhausted')
    );

    const body = await gql.execute(
      { query: `query { user(id: "1") { id } }` },
      { authToken: token }
    );

    // Production should mask internal error messages
    expect(body.errors[0].message).not.toContain('db connection pool');
    expect(body.errors[0].extensions.code).toBe('INTERNAL_SERVER_ERROR');
  });
});

Testing File Uploads

GraphQL multipart uploads (via graphql-upload) require special testing:

describe('Mutation.uploadAvatar', () => {
  it('uploads and processes image', async () => {
    const token = generateToken({ userId: '1', role: 'user' });

    const response = await supertest(app)
      .post('/graphql')
      .set('Authorization', `Bearer ${token}`)
      .field(
        'operations',
        JSON.stringify({
          query: `mutation UploadAvatar($file: Upload!) { uploadAvatar(file: $file) { url } }`,
          variables: { file: null },
        })
      )
      .field('map', JSON.stringify({ '0': ['variables.file'] }))
      .attach('0', Buffer.from('fake-image-data'), {
        filename: 'avatar.jpg',
        contentType: 'image/jpeg',
      });

    expect(response.body.data.uploadAvatar.url).toMatch(/^https?:\/\//);
  });
});

CI Configuration

# .github/workflows/graphql-integration.yml
name: GraphQL Integration Tests

on: [push, pull_request]

jobs:
  test:
    runs-on: ubuntu-latest

    services:
      postgres:
        image: postgres:15
        env:
          POSTGRES_DB: testdb
          POSTGRES_USER: test
          POSTGRES_PASSWORD: test
        ports:
          - 5432:5432
        options: --health-cmd pg_isready --health-interval 10s --health-timeout 5s --health-retries 5

      redis:
        image: redis:7
        ports:
          - 6379:6379

    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with:
          node-version: '20'
          cache: 'npm'
      - run: npm ci
      - name: Run integration tests
        run: npm test -- --testPathPattern=integration
        env:
          DATABASE_URL: postgres://test:test@localhost:5432/testdb
          REDIS_URL: redis://localhost:6379
          JWT_SECRET: test-secret-not-for-production
          NODE_ENV: test

Performance Considerations

Supertest tests are slower than executeOperation tests because they go through the full HTTP stack. Keep your test suite fast by:

Sharing the app instance: Create the Express app once in beforeAll, not in each test
Reusing tokens: Generate JWT tokens once per describe block, not per test
Minimal seeding: Only seed the data each test actually needs
Parallel test files: Jest runs test files in parallel by default — don't fight it with shared state

A typical integration test suite for a medium GraphQL API should complete in under 60 seconds. If it's slower, profile which tests are slowest and look for missing indexes or N+1 queries in your resolvers.
