Game Performance Testing: FPS, Memory Leaks, and Load Testing

// Unity Performance Testing extension (com.unity.test-framework.performance)
using Unity.PerformanceTesting;
using NUnit.Framework;
using UnityEngine.TestTools;
using System.Collections;

public class FPSPerformanceTests
{
    [UnityTest, Performance]
    public IEnumerator MainMenuFPSBenchmark()
    {
        yield return new WaitForSeconds(2);  // Allow scene to stabilize

        using (Measure.Frames().Scope())
        {
            yield return new WaitForSeconds(5);  // Measure for 5 seconds
        }

        // Access results via PerformanceTest.Active.SampleGroups
    }

    [UnityTest, Performance]
    public IEnumerator CombatSceneFPSBenchmark()
    {
        // Load combat scene with many enemies
        yield return LoadScene("CombatBenchmarkScene");
        yield return new WaitForSeconds(2);  // Stabilize

        using (Measure.Frames().WarmupCount(60).MeasurementCount(120).Scope())
        {
            // The framework captures frame timings
            yield return null;
        }
    }

    [UnityTest, Performance]
    public IEnumerator DrawCallCount()
    {
        yield return LoadScene("MaxCrowdScene");

        Measure.Custom(new SampleGroup("Draw Calls", SampleUnit.None),
                       () => UnityStats.drawCalls);

        yield return new WaitForSeconds(3);

        // Assert via custom benchmark comparisons in CI
    }
}

# performance_regression.py
import json
import sys

def check_fps_regression(current_results_path: str,
                          baseline_results_path: str,
                          regression_threshold_pct: float = 10.0) -> bool:
    """
    Fail CI if FPS dropped more than threshold_pct compared to baseline.
    """
    with open(current_results_path) as f:
        current = json.load(f)
    with open(baseline_results_path) as f:
        baseline = json.load(f)

    regressions = []

    for test_name, current_data in current.items():
        if test_name not in baseline:
            continue

        baseline_fps = baseline[test_name]["median_fps"]
        current_fps = current_data["median_fps"]

        regression_pct = ((baseline_fps - current_fps) / baseline_fps) * 100

        if regression_pct > regression_threshold_pct:
            regressions.append({
                "test": test_name,
                "baseline_fps": baseline_fps,
                "current_fps": current_fps,
                "regression_pct": regression_pct
            })

    if regressions:
        print("PERFORMANCE REGRESSIONS DETECTED:")
        for r in regressions:
            print(f"  {r['test']}: {r['baseline_fps']:.1f}→{r['current_fps']:.1f} fps "
                  f"(-{r['regression_pct']:.1f}%)")
        return False

    print(f"No regressions detected (threshold: {regression_threshold_pct}%)")
    return True

if __name__ == "__main__":
    success = check_fps_regression(
        current_results_path="performance-results-current.json",
        baseline_results_path="performance-results-baseline.json"
    )
    sys.exit(0 if success else 1)

[UnityTest]
public IEnumerator NoMemoryLeakOnSceneReload()
{
    // Baseline memory
    System.GC.Collect();
    yield return new WaitForSeconds(0.5f);
    long initialMemory = UnityEngine.Profiling.Profiler.GetTotalAllocatedMemoryLong();

    // Load and unload a scene multiple times
    for (int i = 0; i < 10; i++)
    {
        yield return UnityEngine.SceneManagement.SceneManager.LoadSceneAsync("GameLevel01");
        yield return new WaitForSeconds(1f);
        yield return UnityEngine.SceneManagement.SceneManager.LoadSceneAsync("MainMenu");
        yield return new WaitForSeconds(0.5f);
        System.GC.Collect();
    }

    yield return new WaitForSeconds(1f);
    System.GC.Collect();
    long finalMemory = UnityEngine.Profiling.Profiler.GetTotalAllocatedMemoryLong();

    long growthMB = (finalMemory - initialMemory) / (1024 * 1024);

    Assert.Less(growthMB, 20,
        $"Memory grew by {growthMB}MB after 10 scene reload cycles — possible leak");
}

import subprocess
import time

def track_memory_over_session(package_name: str, duration_minutes: int = 30) -> list:
    """Sample memory every minute for the duration of a play session."""
    samples = []

    for minute in range(duration_minutes):
        result = subprocess.run(
            ["adb", "shell", "dumpsys", "meminfo", package_name, "--scale", "MB"],
            capture_output=True, text=True
        )

        total_pss = 0
        for line in result.stdout.split('\n'):
            if 'TOTAL PSS:' in line or 'TOTAL:' in line:
                parts = line.split()
                for i, part in enumerate(parts):
                    if part.isdigit():
                        total_pss = int(part)
                        break

        samples.append({
            "minute": minute,
            "total_pss_mb": total_pss
        })

        time.sleep(60)

    return samples

def test_memory_stable_over_30_min_session():
    samples = track_memory_over_session("com.yourcompany.yourgame", duration_minutes=30)

    first_5min_avg = sum(s['total_pss_mb'] for s in samples[:5]) / 5
    last_5min_avg = sum(s['total_pss_mb'] for s in samples[-5:]) / 5

    growth_mb = last_5min_avg - first_5min_avg

    assert growth_mb < 50, \
        f"Memory grew by {growth_mb:.1f}MB over 30 minutes — possible leak\n" \
        f"Initial avg: {first_5min_avg:.1f}MB, Final avg: {last_5min_avg:.1f}MB"

// k6 script: simulate players joining and playing
import ws from 'k6/ws';
import { check, sleep } from 'k6';
import { Counter, Trend } from 'k6/metrics';

const matchJoinTime = new Trend('match_join_time_ms');
const disconnections = new Counter('unexpected_disconnections');

export const options = {
  stages: [
    { duration: '5m', target: 500 },    // Ramp to 500 concurrent players
    { duration: '20m', target: 5000 },  // Load test at 5000 players
    { duration: '5m', target: 0 },
  ],
  thresholds: {
    'match_join_time_ms': ['p(95)<3000'],  // 95% join in under 3 seconds
    'unexpected_disconnections': ['count<10'],  // Fewer than 10 drops per run
    ws_sessions: ['rate>0.99'],  // 99%+ successful connections
  },
};

export default function () {
  const playerId = `player-${__VU}-${__ITER}`;

  const start = Date.now();

  const res = ws.connect(
    `wss://gameserver.example.com/ws?player_id=${playerId}`,
    {},
    function(socket) {
      socket.on('open', () => {
        socket.send(JSON.stringify({ type: 'find_match', mode: 'casual' }));
      });

      socket.on('message', (msg) => {
        const data = JSON.parse(msg);

        if (data.type === 'match_found') {
          const joinTime = Date.now() - start;
          matchJoinTime.add(joinTime);

          // Simulate playing for 5-15 minutes
          socket.setTimeout(() => {
            socket.send(JSON.stringify({ type: 'leave_match' }));
            socket.close();
          }, Math.random() * 600000 + 300000);
        }
      });

      socket.on('close', (code) => {
        if (code !== 1000 && code !== 1001) {
          disconnections.add(1);
        }
      });
    }
  );

  check(res, { 'connected': (r) => r && r.status === 101 });
}

def test_server_handles_1000_concurrent_players():
    """Server should maintain <100ms tick latency with 1000 players."""

    # Run k6 load test
    result = subprocess.run([
        "k6", "run",
        "--vus", "1000",
        "--duration", "10m",
        "--out", "json=results.json",
        "game-server-load-test.js"
    ], capture_output=True, text=True)

    # Parse results
    with open("results.json") as f:
        metrics = json.load(f)

    # Check thresholds
    join_p95 = metrics['metrics']['match_join_time_ms']['p(95)']
    assert join_p95 < 3000, f"Match join P95 {join_p95}ms exceeds 3s"

    disconnections = metrics['metrics']['unexpected_disconnections']['count']
    assert disconnections < 10, f"{disconnections} unexpected disconnections"

def generate_performance_report(test_run_id: str) -> str:
    results = load_results(test_run_id)
    baseline = load_baseline_results()

    report = f"""
# Performance Test Report — {test_run_id}
**Date:** {datetime.now().strftime('%Y-%m-%d %H:%M')}

## Frame Rate

| Scene | Baseline P50 | Current P50 | Change | Status |
|-------|-------------|-------------|--------|--------|
"""

    for scene in results['fps_scenes']:
        baseline_fps = baseline['fps'][scene]['p50']
        current_fps = results['fps'][scene]['p50']
        change = current_fps - baseline_fps
        change_pct = (change / baseline_fps) * 100
        status = "✅" if change_pct >= -5 else "⚠️" if change_pct >= -10 else "❌"

        report += f"| {scene} | {baseline_fps:.1f} | {current_fps:.1f} | {change_pct:+.1f}% | {status} |\n"

    report += f"""
## Memory

- Peak memory during session: {results['memory']['peak_mb']:.1f} MB
- Memory at session end: {results['memory']['end_mb']:.1f} MB
- Growth over session: {results['memory']['end_mb'] - results['memory']['start_mb']:.1f} MB

## Server Load (1000 CCU)

- Match join P95: {results['server']['join_p95_ms']:.0f}ms
- Unexpected disconnections: {results['server']['disconnections']}
"""

    return report
