Envoy Proxy Testing: xDS Config, Filter Chains, and Integration Tests

# Validate a static config file
docker run --<span class="hljs-built_in">rm \
  -v $(<span class="hljs-built_in">pwd)/envoy.yaml:/etc/envoy/envoy.yaml \
  envoyproxy/envoy:v1.29.0 \
  envoy --config-path /etc/envoy/envoy.yaml --mode validate

<span class="hljs-comment"># Expected output for valid config:
<span class="hljs-comment"># configuration '/etc/envoy/envoy.yaml' OK

<span class="hljs-comment"># For invalid config:
<span class="hljs-comment"># [error] …Field 'rate_limit_service' is not set.

# .github/workflows/envoy-validate.yml
name: Envoy Config Validation

on:
  pull_request:
    paths:
      - 'envoy/**'

jobs:
  validate:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Validate all Envoy configs
        run: |
          for config in envoy/*.yaml; do
            echo "Validating $config..."
            docker run --rm \
              -v $(pwd)/$config:/etc/envoy/envoy.yaml \
              envoyproxy/envoy:v1.29.0 \
              envoy --config-path /etc/envoy/envoy.yaml --mode validate
            echo "$config: OK"
          done

import yaml
import json
import pytest
from jsonschema import validate, ValidationError

def load_yaml(path):
    with open(path) as f:
        return yaml.safe_load(f)

def test_envoy_bootstrap_has_required_sections():
    config = load_yaml("envoy/envoy.yaml")
    assert "static_resources" in config or "dynamic_resources" in config
    assert "admin" in config

    if "static_resources" in config:
        assert "listeners" in config["static_resources"]
        assert "clusters" in config["static_resources"]

def test_cluster_health_checks_defined():
    config = load_yaml("envoy/envoy.yaml")
    clusters = config["static_resources"]["clusters"]

    for cluster in clusters:
        # Production clusters should have health checks
        if cluster.get("name") != "local_access_log":  # Exempt utility clusters
            assert "health_checks" in cluster, \
                f"Cluster '{cluster['name']}' missing health_checks"

def test_timeouts_configured():
    config = load_yaml("envoy/envoy.yaml")
    listeners = config["static_resources"]["listeners"]

    for listener in listeners:
        for fc in listener.get("filter_chains", []):
            for f in fc.get("filters", []):
                if f.get("name") == "envoy.filters.network.http_connection_manager":
                    hcm = f["typed_config"]
                    route_config = hcm.get("route_config", {})
                    for vhost in route_config.get("virtual_hosts", []):
                        for route in vhost.get("routes", []):
                            timeout = route.get("route", {}).get("timeout")
                            assert timeout is not None, \
                                f"Route missing timeout: {route}"

def test_no_wildcard_cors():
    config = load_yaml("envoy/envoy.yaml")
    config_str = json.dumps(config)

    # Detect overly permissive CORS
    assert '"allow_origin_string_match"' not in config_str or \
           '"prefix": "*"' not in config_str, \
        "Wildcard CORS origin detected — use explicit origins"

# docker-compose.test.yml
version: "3.8"

services:
  envoy:
    image: envoyproxy/envoy:v1.29.0
    command: envoy -c /etc/envoy/envoy-test.yaml
    ports:
      - "10000:10000"  # Proxy port
      - "9901:9901"    # Admin port
    volumes:
      - ./envoy/envoy-test.yaml:/etc/envoy/envoy-test.yaml

  upstream:
    image: kennethreitz/httpbin
    ports:
      - "8080:80"

# envoy/envoy-test.yaml
static_resources:
  listeners:
    - name: listener_0
      address:
        socket_address:
          protocol: TCP
          address: 0.0.0.0
          port_value: 10000
      filter_chains:
        - filters:
            - name: envoy.filters.network.http_connection_manager
              typed_config:
                "@type": type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager
                stat_prefix: ingress_http
                access_log:
                  - name: envoy.access_loggers.stdout
                    typed_config:
                      "@type": type.googleapis.com/envoy.extensions.access_loggers.stream.v3.StdoutAccessLog
                http_filters:
                  - name: envoy.filters.http.router
                    typed_config:
                      "@type": type.googleapis.com/envoy.extensions.filters.http.router.v3.Router
                route_config:
                  name: local_route
                  virtual_hosts:
                    - name: local_service
                      domains: ["*"]
                      routes:
                        - match:
                            prefix: "/"
                          route:
                            cluster: upstream_service
                            timeout: 30s

  clusters:
    - name: upstream_service
      connect_timeout: 5s
      type: LOGICAL_DNS
      lb_policy: ROUND_ROBIN
      load_assignment:
        cluster_name: upstream_service
        endpoints:
          - lb_endpoints:
              - endpoint:
                  address:
                    socket_address:
                      address: upstream
                      port_value: 80

admin:
  address:
    socket_address:
      protocol: TCP
      address: 0.0.0.0
      port_value: 9901

import pytest
import httpx
import time

PROXY = "http://localhost:10000"
ADMIN = "http://localhost:9901"

@pytest.fixture(scope="session", autouse=True)
def wait_for_envoy():
    for _ in range(30):
        try:
            r = httpx.get(f"{ADMIN}/ready")
            if r.status_code == 200:
                return
        except httpx.ConnectError:
            pass
        time.sleep(1)
    raise RuntimeError("Envoy did not become ready")

def test_proxy_forwards_get_request():
    r = httpx.get(f"{PROXY}/get")
    assert r.status_code == 200
    assert "args" in r.json()

def test_proxy_preserves_request_headers():
    r = httpx.get(
        f"{PROXY}/headers",
        headers={"X-Custom-Header": "test-value"}
    )
    assert r.status_code == 200
    received = r.json()["headers"]
    assert received.get("X-Custom-Header") == "test-value"

def test_proxy_adds_via_header():
    """Envoy adds a Via header to identify proxy hops."""
    r = httpx.get(f"{PROXY}/headers")
    received = r.json()["headers"]
    assert "Via" in received

def test_unknown_route_returns_404():
    r = httpx.get(f"{PROXY}/this-route-does-not-exist-xyz")
    # Depends on config — might be 404 from upstream or 404 from Envoy routing
    assert r.status_code in (404, 503)

# Add to http_filters in envoy-test.yaml (before router):
- name: envoy.filters.http.jwt_authn
  typed_config:
    "@type": type.googleapis.com/envoy.extensions.filters.http.jwt_authn.v3.JwtAuthentication
    providers:
      test_provider:
        issuer: "https://test-issuer.example.com"
        local_jwks:
          inline_string: |
            {
              "keys": [{
                "kty": "oct",
                "kid": "test-key",
                "alg": "HS256",
                "k": "c2VjcmV0"
              }]
            }
        forward: true
        payload_in_metadata: "jwt_payload"
    rules:
      - match:
          prefix: "/protected"
        requires:
          provider_name: "test_provider"
      - match:
          prefix: "/public"
        # No requires = public endpoint

import jwt as pyjwt
from datetime import datetime, timedelta

def make_test_jwt(expired=False, wrong_issuer=False):
    payload = {
        "sub": "test-user",
        "iss": "https://evil.example.com" if wrong_issuer else "https://test-issuer.example.com",
        "exp": datetime.utcnow() + (timedelta(hours=-1) if expired else timedelta(hours=1))
    }
    return pyjwt.encode(payload, "secret", algorithm="HS256")

def test_protected_route_requires_jwt():
    r = httpx.get(f"{PROXY}/protected/resource")
    assert r.status_code == 401

def test_valid_jwt_accesses_protected_route():
    token = make_test_jwt()
    r = httpx.get(
        f"{PROXY}/protected/resource",
        headers={"Authorization": f"Bearer {token}"}
    )
    assert r.status_code == 200

def test_expired_jwt_rejected():
    token = make_test_jwt(expired=True)
    r = httpx.get(
        f"{PROXY}/protected/resource",
        headers={"Authorization": f"Bearer {token}"}
    )
    assert r.status_code == 401
    # Envoy returns Www-Authenticate on JWT failures
    assert "Www-Authenticate" in r.headers or "WWW-Authenticate" in r.headers

def test_wrong_issuer_rejected():
    token = make_test_jwt(wrong_issuer=True)
    r = httpx.get(
        f"{PROXY}/protected/resource",
        headers={"Authorization": f"Bearer {token}"}
    )
    assert r.status_code == 401

def test_public_route_accessible_without_jwt():
    r = httpx.get(f"{PROXY}/public/health")
    assert r.status_code == 200

def test_rate_limit_headers_present():
    """Envoy should return rate limit headers from the rate limit service."""
    r = httpx.get(f"{PROXY}/get", headers={"X-User-Id": "test-user"})
    # Rate limit headers vary by configuration:
    assert any(h in r.headers for h in [
        "x-ratelimit-limit",
        "x-envoy-ratelimited",
        "ratelimit-limit"
    ])

def test_rate_limited_request_returns_429():
    """After exhausting limits, Envoy returns 429 with retry-after."""
    headers = {"X-User-Id": "heavy-user"}

    # Make many requests to trigger rate limiting
    for _ in range(200):
        r = httpx.get(f"{PROXY}/get", headers=headers)
        if r.status_code == 429:
            assert "retry-after" in r.headers or "x-envoy-ratelimited" in r.headers
            return

    # If no 429 was returned, check that rate limit service is actually configured
    pytest.skip("Rate limit not triggered — check rate limit service configuration")

import grpc
from envoy.service.discovery.v3 import ads_pb2_grpc

def test_control_plane_reachable():
    """Envoy should be able to connect to the xDS control plane."""
    admin_stats = httpx.get(f"{ADMIN}/stats")
    stats_text = admin_stats.text

    # Check xDS connection is established
    assert "xds_grpc" in stats_text, "No xDS gRPC stats found"

    # Check for update failures
    cds_failures = [
        line for line in stats_text.splitlines()
        if "cds.update_failure" in line
    ]
    assert not any(
        int(line.split(":")[-1].strip()) > 0
        for line in cds_failures
    ), f"CDS update failures detected: {cds_failures}"

def test_lds_config_applied():
    """Listener Discovery Service config should be applied."""
    admin_stats = httpx.get(f"{ADMIN}/stats")

    # lds.update_success should be > 0
    for line in admin_stats.text.splitlines():
        if "lds.update_success" in line:
            count = int(line.split(":")[-1].strip())
            assert count > 0, "LDS updates not applied"
            return

    pytest.fail("lds.update_success stat not found")

def test_cluster_discovery_applied():
    """Check clusters from CDS are loaded."""
    clusters_response = httpx.get(f"{ADMIN}/clusters?format=json")
    clusters = clusters_response.json()

    cluster_names = [c["name"] for c in clusters.get("cluster_statuses", [])]
    assert "upstream_service" in cluster_names, \
        f"Expected cluster not found. Got: {cluster_names}"

def test_admin_ready_endpoint():
    r = httpx.get(f"{ADMIN}/ready")
    assert r.status_code == 200
    assert r.text.strip() == "LIVE"

def test_admin_health_check():
    r = httpx.get(f"{ADMIN}/healthcheck/ok")
    assert r.status_code == 200

def test_stats_accessible():
    r = httpx.get(f"{ADMIN}/stats")
    assert r.status_code == 200
    stats = r.text
    assert "http.ingress_http.rq_total" in stats

def test_config_dump_readable():
    """Admin config dump should return valid JSON."""
    r = httpx.get(f"{ADMIN}/config_dump")
    assert r.status_code == 200
    config = r.json()
    assert "configs" in config

def test_upstream_cluster_healthy():
    """All configured clusters should have healthy endpoints."""
    r = httpx.get(f"{ADMIN}/clusters?format=json")
    assert r.status_code == 200

    data = r.json()
    for cluster in data.get("cluster_statuses", []):
        for host in cluster.get("host_statuses", []):
            health = host.get("health_status", {})
            eds_health = health.get("eds_health_status", "HEALTHY")
            assert eds_health == "HEALTHY", \
                f"Unhealthy host in cluster '{cluster['name']}': {host['address']}"

def test_outlier_ejection_on_consecutive_errors(flaky_upstream):
    """After consecutive 5xx errors, Envoy ejects the upstream host."""
    # Configure upstream to return 500s
    flaky_upstream.set_response_code(500)

    # Make requests until Envoy ejects the host (or times out)
    ejections = 0
    for _ in range(10):
        r = httpx.get(f"{PROXY}/get")
        time.sleep(0.1)

    # Check admin stats for ejections
    stats = httpx.get(f"{ADMIN}/stats").text
    ejection_stats = [
        line for line in stats.splitlines()
        if "outlier_detection.ejections_active" in line
    ]

    assert any(
        int(line.split(":")[-1].strip()) > 0
        for line in ejection_stats
    ), "No outlier ejections detected despite 5xx responses"

def test_tls_traffic_matches_tls_chain():
    """TLS connections should be handled by the TLS filter chain."""
    # Connect via HTTPS (if TLS listener configured)
    try:
        r = httpx.get(
            "https://localhost:10443/get",
            verify=False  # Test cert — not for production
        )
        assert r.status_code == 200
    except httpx.ConnectError:
        pytest.skip("TLS listener not configured in this test environment")

def test_plaintext_traffic_matches_plaintext_chain():
    """Non-TLS connections use the plaintext filter chain."""
    r = httpx.get(f"{PROXY}/get")
    assert r.status_code == 200

def test_filter_chain_order_matters():
    """Verify filter order: auth → rate limit → router."""
    # Without credentials: should fail at auth (401), not rate limit (429)
    r = httpx.get(f"{PROXY}/protected/resource")
    assert r.status_code == 401  # Auth filter runs first

    # Spam requests without auth — should still get 401, not 429
    for _ in range(50):
        r = httpx.get(f"{PROXY}/protected/resource")
        assert r.status_code == 401, \
            "Got non-401 — rate limiter may be running before auth filter"

# Validate Istio config before applying
istioctl analyze -n your-namespace

<span class="hljs-comment"># Check proxy config for a specific pod
istioctl proxy-config routes your-pod -n your-namespace --name 80

<span class="hljs-comment"># Verify listeners
istioctl proxy-config listeners your-pod -n your-namespace

<span class="hljs-comment"># Check clusters
istioctl proxy-config clusters your-pod -n your-namespace

import subprocess
import json

def test_istio_virtual_service_applied(pod_name, namespace):
    """VirtualService route rules should appear in proxy config."""
    result = subprocess.run(
        ["istioctl", "proxy-config", "routes", pod_name,
         "-n", namespace, "--name", "80", "-o", "json"],
        capture_output=True, text=True
    )
    assert result.returncode == 0

    routes = json.loads(result.stdout)
    route_names = [r.get("name") for r in routes]

    assert any("my-service" in name for name in route_names), \
        f"VirtualService not found in proxy routes. Got: {route_names}"

Go To http://envoy-proxy/ready
Status Should Be 200

Go To http://envoy-admin:9901/stats
Page Should Contain http.ingress_http.rq_total
