Disaster Recovery Testing: Runbooks, Game Days, and Tabletop Exercises

def measure_recovery_time(start_failure_time, service_restored_time) -> float:
    """Actual RTO achieved during a DR drill."""
    return (service_restored_time - start_failure_time).total_seconds() / 60

def measure_data_loss(last_good_backup_time, failure_time) -> float:
    """Actual RPO — data loss window in minutes."""
    return (failure_time - last_good_backup_time).total_seconds() / 60

# Verify against targets
actual_rto_minutes = measure_recovery_time(failure_start, service_restored)
assert actual_rto_minutes <= TARGET_RTO_MINUTES, \
    f"RTO {actual_rto_minutes:.1f}min exceeds target {TARGET_RTO_MINUTES}min"

# Runbook: Database Primary Failover

**Last tested:** 2026-01-15 by: @alice
**RTO target:** 15 minutes
**RPO target:** 60 seconds

## Prerequisites
- [ ] PagerDuty incident created: `https://pd.example.com/...`
- [ ] War room Slack channel opened: `#incident-YYYY-MM-DD`
- [ ] Primary on-call confirmed: `/pd escalate`

## Step 1: Confirm Failure (2 min)

Verify the primary is actually failing (not a monitoring glitch):

```bash
kubectl exec -it postgres-primary-0 -n database -- \
  psql -U postgres -c "SELECT 1"

# Identify which replica has the most recent WAL position
kubectl <span class="hljs-built_in">exec -it postgres-replica-0 -n database -- \
  psql -U postgres -c <span class="hljs-string">"SELECT pg_last_wal_receive_lsn()"

kubectl <span class="hljs-built_in">exec -it postgres-replica-1 -n database -- \
  psql -U postgres -c <span class="hljs-string">"SELECT pg_last_wal_receive_lsn()"

<span class="hljs-comment"># Promote the replica with the higher LSN (e.g., replica-0)
kubectl <span class="hljs-built_in">exec -it postgres-replica-0 -n database -- \
  pg_ctl promote -D /var/lib/postgresql/data

kubectl exec -it postgres-replica-0 -n database -- \
  psql -U postgres -c <span class="hljs-string">"SELECT pg_is_in_recovery()"

kubectl patch service postgres-primary -n database \
  -p '{"spec":{"selector":{"statefulset.kubernetes.io/pod-name":"postgres-replica-0"}}}'

curl -s https://api.example.com/health | jq <span class="hljs-string">'.database'

./scripts/smoke-test.sh https://api.example.com

### Testing Runbooks Automatically

```python
import subprocess
import re

def validate_runbook(runbook_path: str) -> list:
    """
    Static analysis of a runbook to catch common issues.
    Returns list of warnings.
    """
    with open(runbook_path) as f:
        content = f.read()

    warnings = []

    # Check for "Last tested" date
    if "Last tested" not in content:
        warnings.append("MISSING: 'Last tested' date — runbook may be stale")
    else:
        match = re.search(r'Last tested:\s*(\d{4}-\d{2}-\d{2})', content)
        if match:
            from datetime import datetime
            test_date = datetime.strptime(match.group(1), "%Y-%m-%d")
            days_since = (datetime.now() - test_date).days
            if days_since > 90:
                warnings.append(f"STALE: Runbook not tested in {days_since} days (threshold: 90)")

    # Check for success criteria
    code_blocks = re.findall(r'```bash(.*?)```', content, re.DOTALL)
    for i, block in enumerate(code_blocks):
        if "Expected" not in content.split("```bash")[i+1].split("```")[0][:500]:
            warnings.append(f"MISSING: No 'Expected' output defined after code block {i+1}")

    # Check for RTO target
    if "RTO target" not in content:
        warnings.append("MISSING: RTO target not defined")

    # Check for stakeholder notification step
    if "Notify" not in content and "stakeholder" not in content.lower():
        warnings.append("MISSING: No stakeholder notification step")

    return warnings

def test_runbooks_are_valid():
    import glob
    runbook_files = glob.glob("runbooks/*.md")

    all_warnings = {}
    for runbook in runbook_files:
        warnings = validate_runbook(runbook)
        if warnings:
            all_warnings[runbook] = warnings

    assert len(all_warnings) == 0, \
        "Runbook issues found:\n" + "\n".join(
            f"  {rb}:\n" + "\n".join(f"    - {w}" for w in warns)
            for rb, warns in all_warnings.items()
        )

SCENARIO: Database corruption after schema migration

TIME: Thursday, 2:15 PM
CONTEXT: A new schema migration ran successfully in staging but is producing
         data corruption on the production database.

SYMPTOMS:
- Sentry is showing DatabaseError exceptions at 30x normal rate
- A few customers are reporting they can't access their data
- The migration ran 45 minutes ago
- The migration cannot be rolled back (adds a NOT NULL column)

QUESTIONS TO DISCUSS:
1. Who are the first people to be notified? (Who owns the incident?)
2. What is the first thing you check?
3. How do you assess the scope of corruption?
4. What options do you have? (Point-in-time restore, data repair script, manual fixes?)
5. Who makes the decision to restore from backup?
6. How do you communicate with affected customers?
7. What is your RTO from this point? What is the RPO (data loss)?

## Before the Tabletop

- [ ] Select scenario (rotate types: database, network, third-party, human error)
- [ ] Confirm all relevant team members can attend (on-call, engineering leads, support)
- [ ] Send scenario description 24h in advance OR keep it secret for realism

## During the Tabletop

- [ ] State the ground rules: no blame, focus on process
- [ ] Read the scenario aloud
- [ ] Ask probing questions when answers are vague ("Who specifically does that?")
- [ ] Note where participants disagree or are uncertain
- [ ] Track open questions that need follow-up
- [ ] Time the exercise (aim for 60-90 minutes)

## After the Tabletop

- [ ] Document findings within 48 hours
- [ ] Create tickets for each gap found
- [ ] Schedule follow-up to verify gaps are closed
- [ ] Update runbooks based on decisions made during the tabletop

## Pre-Game Day (1 week before)

- [ ] Define success criteria and metrics to track
- [ ] Set communication plan (who notifies whom, what channels)
- [ ] Notify affected teams and stakeholders
- [ ] Create rollback plan (how to stop the game day if something goes wrong)
- [ ] Verify staging environment is production-equivalent

## Day-Of Setup (30 min before)

- [ ] Open war room channel
- [ ] Confirm all participants are available
- [ ] Verify monitoring dashboards are accessible
- [ ] Start recording metrics baseline (throughput, error rate, latency)
- [ ] Confirm rollback command is ready to execute

## During the Game Day

- [ ] Document each action with timestamp
- [ ] Track actual vs. expected RTO at each step
- [ ] Record all surprises (things that didn't work as expected)
- [ ] If system enters uncontrolled state → execute rollback → pause game day

## Post-Game Day (within 24 hours)

- [ ] Document actual RTO and RPO achieved
- [ ] List all runbook steps that failed or needed updates
- [ ] Create action items with owners and deadlines
- [ ] Schedule next game day (quarterly is common)

def calculate_dr_maturity_score(runbooks: list, game_days: list) -> dict:
    """Score DR maturity across key dimensions."""

    return {
        "runbook_coverage": {
            "score": len([r for r in runbooks if r.last_tested_within_90_days]) / len(runbooks),
            "description": "Fraction of runbooks tested within 90 days"
        },
        "rto_achievement": {
            "score": len([gd for gd in game_days if gd.actual_rto <= gd.target_rto]) / len(game_days),
            "description": "Fraction of game days that met RTO target"
        },
        "game_day_frequency": {
            "score": min(1.0, len(game_days) / 4),  # 4 per year = 1.0
            "description": "Game days per year (target: 4)"
        },
        "tabletop_frequency": {
            "score": min(1.0, len([t for t in tabletops if t.age_days < 90]) / 4),
            "description": "Tabletop exercises per quarter"
        }
    }
