End-to-End Checkout Flow Testing: Playwright Scripts, Edge Cases, and Cross-Browser Payment Forms

HelpMeTest

18 May 2026 — 7 min read

End-to-end checkout testing with Playwright covers the critical path from cart to order confirmation, including payment form interactions, address validation, edge cases like session expiry, and cross-browser compatibility for payment iframes.

Why Checkout Needs Dedicated E2E Tests

Checkout is the most valuable flow in any e-commerce application. A broken checkout is a direct revenue loss — and it often breaks in ways that unit and integration tests miss:

Payment iframes render differently across browsers
Address autocomplete and form autofill interfere with test selectors
Session tokens expire mid-checkout on slow connections
Mobile keyboards shift the viewport and hide the pay button
Third-party scripts (analytics, chat widgets) block checkout button clicks

End-to-end tests with Playwright catch these issues because they run against a real browser.

Project Setup

npm install -D @playwright/test
npx playwright install chromium firefox webkit

// playwright.config.js
import { defineConfig, devices } from '@playwright/test';

export default defineConfig({
  testDir: './tests/e2e',
  timeout: 60000,
  retries: process.env.CI ? 2 : 0,
  workers: process.env.CI ? 2 : undefined,
  reporter: process.env.CI ? 'github' : 'html',

  use: {
    baseURL: process.env.BASE_URL || 'http://localhost:3000',
    trace: 'on-first-retry',
    video: 'retain-on-failure',
    screenshot: 'only-on-failure',
  },

  projects: [
    { name: 'chromium', use: { ...devices['Desktop Chrome'] } },
    { name: 'firefox', use: { ...devices['Desktop Firefox'] } },
    { name: 'webkit', use: { ...devices['Desktop Safari'] } },
    { name: 'mobile-chrome', use: { ...devices['Pixel 5'] } },
    { name: 'mobile-safari', use: { ...devices['iPhone 13'] } },
  ],
});

Core Checkout Flow Test

This is the test you run on every commit. It must always pass.

// tests/e2e/checkout.spec.js
import { test, expect } from '@playwright/test';
import { addToCart, fillShippingAddress, fillPaymentCard } from './helpers/checkout';

test.describe('Checkout flow', () => {
  test.beforeEach(async ({ page }) => {
    // Use a saved auth state if the store requires login
    // await page.context().addCookies([...]); // or use storageState
  });

  test('completes checkout with credit card', async ({ page }) => {
    // Step 1: Add product to cart
    await page.goto('/products/test-product-always-in-stock');
    await page.click('[data-testid="add-to-cart"]');

    // Verify cart update
    await expect(page.locator('[data-testid="cart-count"]')).toHaveText('1');

    // Step 2: Proceed to checkout
    await page.goto('/cart');
    await page.click('[data-testid="checkout-button"]');
    await expect(page).toHaveURL(/checkout/);

    // Step 3: Fill shipping address
    await page.fill('[name="email"]', 'test@example.com');
    await page.fill('[name="firstName"]', 'Test');
    await page.fill('[name="lastName"]', 'User');
    await page.fill('[name="address1"]', '123 Main Street');
    await page.fill('[name="city"]', 'San Francisco');
    await page.selectOption('[name="provinceCode"]', 'CA');
    await page.fill('[name="zip"]', '94105');
    await page.selectOption('[name="countryCode"]', 'US');

    await page.click('[data-testid="continue-to-shipping"]');

    // Step 4: Select shipping method
    await page.waitForSelector('[data-testid="shipping-method"]');
    await page.click('[data-testid="shipping-method-standard"]');
    await page.click('[data-testid="continue-to-payment"]');

    // Step 5: Enter payment details
    // Stripe card element renders in an iframe
    const cardFrame = page.frameLocator('iframe[title="Secure card payment input frame"]')
      .or(page.frameLocator('iframe[name^="__privateStripeFrame"]'));

    await cardFrame.locator('[name="cardnumber"]').fill('4242424242424242');
    await cardFrame.locator('[name="exp-date"]').fill('12/28');
    await cardFrame.locator('[name="cvc"]').fill('123');

    // Step 6: Verify order summary before placing
    const total = await page.locator('[data-testid="order-total"]').textContent();
    expect(parseFloat(total.replace(/[^0-9.]/g, ''))).toBeGreaterThan(0);

    // Step 7: Place order
    await page.click('[data-testid="place-order"]');

    // Step 8: Verify confirmation page
    await expect(page).toHaveURL(/order-confirmation|thank-you/, { timeout: 15000 });
    await expect(page.locator('[data-testid="order-number"]')).toBeVisible();
    await expect(page.locator('[data-testid="confirmation-email"]')).toContainText('test@example.com');
  });
});

Edge Case Tests

Declined Card

test('shows clear error when card is declined', async ({ page }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/checkout');
  await fillShippingAddress(page);
  await page.click('[data-testid="continue-to-payment"]');

  await fillPaymentCard(page, '4000000000000002'); // Always declined

  await page.click('[data-testid="place-order"]');

  // Should stay on checkout, show error
  await expect(page).toHaveURL(/checkout/);
  const error = page.locator('[data-testid="payment-error"]');
  await expect(error).toBeVisible();
  await expect(error).toContainText(/declined|card/i);

  // Verify form is still usable (user can retry)
  await expect(page.locator('[data-testid="place-order"]')).toBeEnabled();
});

Insufficient Funds

test('shows specific error for insufficient funds', async ({ page }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/checkout');
  await fillShippingAddress(page);
  await page.click('[data-testid="continue-to-payment"]');

  await fillPaymentCard(page, '4000000000009995'); // Insufficient funds

  await page.click('[data-testid="place-order"]');

  await expect(page.locator('[data-testid="payment-error"]')).toContainText(
    /insufficient|funds/i
  );
});

Out-of-Stock Race Condition

test('handles item going out of stock during checkout', async ({ page, request }) => {
  // Add item to cart
  await addToCart(page, '/products/limited-stock-item');
  await page.goto('/checkout');
  await fillShippingAddress(page);
  await page.click('[data-testid="continue-to-payment"]');

  // Simulate stock being depleted while user is on payment step
  await request.post('/api/test/deplete-stock', {
    data: { sku: 'limited-stock-item' },
    headers: { 'X-Test-Secret': process.env.TEST_SECRET },
  });

  await fillPaymentCard(page, '4242424242424242');
  await page.click('[data-testid="place-order"]');

  // Should show helpful out-of-stock message, not a generic error
  await expect(page.locator('[data-testid="stock-error"]')).toContainText(
    /no longer available|out of stock/i
  );
});

Session Expiry During Checkout

test('recovers gracefully from expired session', async ({ page, context }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/checkout');
  await fillShippingAddress(page);

  // Expire the session by clearing auth cookies
  await context.clearCookies();

  await page.click('[data-testid="continue-to-payment"]');

  // Should either redirect to login or show session-expired notice
  const url = page.url();
  const hasLoginRedirect = url.includes('login') || url.includes('sign-in');
  const hasSessionError = await page.locator('[data-testid="session-error"]').isVisible();

  expect(hasLoginRedirect || hasSessionError).toBe(true);
});

Empty Cart Checkout Prevention

test('cannot checkout with empty cart', async ({ page }) => {
  // Go directly to checkout with empty cart
  await page.goto('/checkout');

  // Should redirect to cart or show empty cart message
  const redirectedToCart = page.url().includes('/cart');
  const hasEmptyCartMessage = await page.locator('[data-testid="empty-cart"]').isVisible();

  expect(redirectedToCart || hasEmptyCartMessage).toBe(true);

  // Checkout button should not be present
  await expect(page.locator('[data-testid="place-order"]')).not.toBeVisible();
});

Coupon Code Application

test('applies valid coupon code and recalculates total', async ({ page }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/cart');

  const originalTotal = await page.locator('[data-testid="cart-total"]').textContent();

  // Apply coupon
  await page.fill('[data-testid="coupon-input"]', 'SAVE10');
  await page.click('[data-testid="apply-coupon"]');

  await expect(page.locator('[data-testid="coupon-success"]')).toBeVisible();
  await expect(page.locator('[data-testid="discount-line"]')).toBeVisible();

  const newTotal = await page.locator('[data-testid="cart-total"]').textContent();
  const originalAmount = parseFloat(originalTotal.replace(/[^0-9.]/g, ''));
  const newAmount = parseFloat(newTotal.replace(/[^0-9.]/g, ''));

  expect(newAmount).toBeLessThan(originalAmount);
});

test('shows error for invalid coupon code', async ({ page }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/cart');

  await page.fill('[data-testid="coupon-input"]', 'NOTACODE');
  await page.click('[data-testid="apply-coupon"]');

  await expect(page.locator('[data-testid="coupon-error"]')).toContainText(
    /invalid|not found|expired/i
  );
});

Cross-Browser Payment Form Testing

Payment forms (especially Stripe's card element) render differently across browsers. These tests verify consistent behavior.

// tests/e2e/payment-crossbrowser.spec.js
import { test, expect } from '@playwright/test';

// This test runs on all browsers defined in playwright.config.js
test('payment form is functional across browsers', async ({ page, browserName }) => {
  await addToCart(page, '/products/test-product');
  await page.goto('/checkout');
  await fillShippingAddress(page);
  await page.click('[data-testid="continue-to-payment"]');

  // Stripe iframe selector may differ by browser
  const iframeSelectors = [
    'iframe[title="Secure card payment input frame"]',
    'iframe[name^="__privateStripeFrame"]',
    'iframe[src*="stripe.com"]',
  ];

  let cardFrame = null;
  for (const selector of iframeSelectors) {
    const iframe = page.frameLocator(selector);
    const exists = await iframe.locator('[name="cardnumber"]').count();
    if (exists > 0) {
      cardFrame = iframe;
      break;
    }
  }

  expect(cardFrame, `Stripe card frame not found in ${browserName}`).not.toBeNull();

  await cardFrame.locator('[name="cardnumber"]').fill('4242424242424242');
  await cardFrame.locator('[name="exp-date"]').fill('12/28');
  await cardFrame.locator('[name="cvc"]').fill('123');

  // Verify card is accepted before submission
  await expect(cardFrame.locator('[name="cardnumber"]')).toHaveValue(/4242/);

  await page.click('[data-testid="place-order"]');
  await expect(page).toHaveURL(/confirmation|thank-you/, { timeout: 20000 });
});

Mobile-Specific Payment Tests

test('checkout works on mobile with virtual keyboard', async ({ page }) => {
  // This test runs on mobile browser via playwright.config.js devices
  await addToCart(page, '/products/test-product');
  await page.goto('/checkout');

  // Verify mobile layout
  const viewport = page.viewportSize();
  expect(viewport.width).toBeLessThan(600);

  // Verify the checkout form is scrollable and not clipped
  await page.fill('[name="email"]', 'test@example.com');

  // Tap the first name field — on mobile, this triggers the keyboard
  await page.tap('[name="firstName"]');
  await page.fill('[name="firstName"]', 'Test');

  // Verify the continue button is accessible (not hidden behind keyboard)
  const continueBtn = page.locator('[data-testid="continue-to-shipping"]');
  await continueBtn.scrollIntoViewIfNeeded();
  await expect(continueBtn).toBeInViewport();
  await continueBtn.tap();

  await expect(page).toHaveURL(/shipping|payment/);
});

Test Helpers

Create reusable helpers to keep test code DRY:

// tests/e2e/helpers/checkout.js

export async function addToCart(page, productPath) {
  await page.goto(productPath);
  await page.waitForSelector('[data-testid="add-to-cart"]');
  await page.click('[data-testid="add-to-cart"]');
  await page.waitForSelector('[data-testid="cart-count"]');
}

export async function fillShippingAddress(page, opts = {}) {
  const address = {
    email: 'test@example.com',
    firstName: 'Test',
    lastName: 'User',
    address1: '123 Main St',
    city: 'San Francisco',
    state: 'CA',
    zip: '94105',
    country: 'US',
    ...opts,
  };

  await page.fill('[name="email"]', address.email);
  await page.fill('[name="firstName"]', address.firstName);
  await page.fill('[name="lastName"]', address.lastName);
  await page.fill('[name="address1"]', address.address1);
  await page.fill('[name="city"]', address.city);

  const stateSelector = page.locator('[name="provinceCode"], [name="state"]').first();
  await stateSelector.selectOption(address.state);

  await page.fill('[name="zip"]', address.zip);

  const countrySelector = page.locator('[name="countryCode"], [name="country"]').first();
  await countrySelector.selectOption(address.country);
}

export async function fillPaymentCard(page, cardNumber = '4242424242424242') {
  const iframeLocator = page.frameLocator('iframe[title="Secure card payment input frame"]')
    .or(page.frameLocator('iframe[name^="__privateStripeFrame"]'));

  await iframeLocator.locator('[name="cardnumber"]').fill(cardNumber);
  await iframeLocator.locator('[name="exp-date"]').fill('12/28');
  await iframeLocator.locator('[name="cvc"]').fill('123');
}

CI Integration

# .github/workflows/e2e.yml
name: Checkout E2E Tests

on:
  push:
    branches: [main]
  pull_request:

jobs:
  e2e-checkout:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with:
          node-version: '20'
      - run: npm ci
      - run: npx playwright install --with-deps
      - name: Start dev server
        run: npm run dev &
        env:
          STRIPE_SECRET_KEY: ${{ secrets.STRIPE_TEST_SECRET_KEY }}
          STRIPE_PUBLISHABLE_KEY: ${{ secrets.STRIPE_TEST_PUBLISHABLE_KEY }}
      - name: Wait for server
        run: npx wait-on http://localhost:3000 --timeout 30000
      - name: Run checkout E2E tests
        run: npx playwright test tests/e2e/checkout.spec.js
        env:
          BASE_URL: http://localhost:3000
          TEST_SECRET: ${{ secrets.E2E_TEST_SECRET }}
      - uses: actions/upload-artifact@v4
        if: failure()
        with:
          name: playwright-report
          path: playwright-report/

Summary

End-to-end checkout testing with Playwright should cover:

The happy path — successful card payment from cart to confirmation
Payment failures — declined card, insufficient funds, expired card
Edge cases — out-of-stock race conditions, session expiry, empty cart
Cross-browser — Chrome, Firefox, Safari, and mobile browsers
Form interactions — coupon codes, address validation, shipping selection

Keep the test count small — fewer than 20 checkout E2E tests is a sign of good discipline. If you have 50+ checkout E2E tests, most of them should be unit or integration tests instead. Every E2E test you add multiplies your CI time across all browsers in your test matrix.
